POWERLINK Bus module – SK CU4-POL
2 TI 275271018 - 4913
Bus specification
POWERLINK Max. 100 MBaud Cable Min. Ethernet CAT-5
Electrical isolation 500 V
eff
Max. cable length 100 m between two modules
Bus connection Screw terminals Shield Direct to PE
bus termination performed automatically PE connection via PE screw connection
Status display 6 LEDs in the terminal box
Topology Star, tree, linear bus
Performance
Update interval for process data between module and frequency inverter
≈ 2.5 ms
Parameter read access on the frequency inverter
≈ 25 ms
Parameter write access with storage in EEPROM
≈ 70 ms
Cycle times 400 µs … 60 ms
Pos : 5 /T ec hnis che Inf or mationen/ SK xU x - Bus - Er wei ter ung en/ Allgemein - Sys temübergreif end/D erating [SK CU 4 - . ..] @ 4\ mod_1378288335408_388. doc x @ 92917 @ 5 @ 1
Derating
ATTENTION Derating
Depending on the installation location of the module (SK 180E, SK 190E or SK 2xxE), the operating mode (S1,
S3 ...) and the installation type (wall-mounting, motor -mounting) of the frequency inverter as well as the type of
motor used (IE1 / IE2 / ...) restrictions to the permissible ambient temperature must be taken into account. If the
permissible ambient temperature is exceeded, the module may heat up to an impermissible extent and switch off
with an error message (E104.0).
Maximum ambient temperature *
Operating mode Installation type SK 180E / SK 190E SK 2xxE
S1 Motor 25°C 30°C
S3 ED 50 %, 10min Motor 40°C n. s.
S3 ED 70 %, 10min Motor n. s. 40°C
S1 Wall (unventilated) 37°C 42°C
S1 Wall (ventilated) 47°C 48°C
* The limits of the frequency inverter must not be exceeded (refer to the frequency inverter manual).
Pos : 6 /T ec hnis che Inf or mationen/ SK xU x - Bus - Er wei ter ung en/ Powerlink/M erkmal e [ PO L Allgemei n] @ 3\ mod_1377869060850_388. doc x @ 92057 @ 5 @ 1
Module features
Hot Plugging (CN connection during operation) Yes
Isochronous (PDO) Yes, Statistical Mapping
Number of process data 12 Byte (SK TU3-…),
50 Byte (SK xU4-…)
Asynchronous Data (SDO over ASND or UDP/IP) Yes
Cross Traffic No, no direct communication between CN
Addressing via DIP switch, module parameters possible
Access for NORD diagnosis tool via Diagnostic socket on the device (if available) or possibly
via frequency inverter and UDP Ethernet protocol
