Milestone XProtect Analytics 2.2 – BOSCH VCA; Administrator’s Manual
www.milestonesys.com Page 31 Event Mapping Tool
4. Select the protocol on which the surveillance server listens for generic event data, either
TCP or UDP. Again, your selection must match what has been specified for the required
generic event on the surveillance server.
5. Optionally, you are able to send the data defined in step 2 to an additional host.
Sending data about analytics detections to an additional host can be interesting in several
scenarios, depending on your organization’s needs. For example if you want to combine
two or more analytics detections in order to present them as one combined detection to
users in the Smart Client. To combine analytics detections you use the Event Proxy Tool,
accessed by double-clicking the file VideoOS.EventProxy.ProxySetup.exe in the XProtect
Analytics installation folder, which also contains documentation for the Event Proxy Tool. If
using the Event Proxy Tool to combine analytics detections, you would use the Event
Mapping Tool’s Additional host fields to specify the address, port and protocol on which the
Event Proxy Tool listens for input.
Specify the address of the additional host in the Additional output host field, the required
port number in the Additional output port field, and the required protocol in the Additional
output event protocol field.
6. Save your event mapping by clicking the button in the Event Mapping Tool’s toolbar.
Repeat if you want other analytics detections to trigger other generic events or sending of
data to additional hosts.
7. Open the XProtect Analytics Administrator application and restart the server service by
clicking the Restart Server button in the Administrator application’s toolbar .
Using the Event Mapping Tool’s Toolbar
Save: Lets you save changes to your settings.
Cut: Lets you cut an item for pasting somewhere else.
Copy: Lets you copy an item for pasting somewhere else.
Paste: Lets you paste an item copied or cut from somewhere else.
Delete: Lets you delete an item.
Refresh: Lets you refresh the connection to the relevant XProtect Analytics plugin and its
associated surveillance ser(s).
Use this command the first time you access the Event Mapping Tool as well as every time
you have made changes to settings in the XProtect Analytics Administrator application or to
the surveillance server’s event configuration.
Help: Lets you access the Event Mapping Tool’s built-in help system, which works in the
same way as the BOSCH VCA Administrator’s built-in help system. See Using the Built-in
Help System on page 26 for more information.
