ThreadChecker
Specifications
ELECTRICAL
INPUT
Voltage:
15 VDC to 30 VDC (reverse polarity protected)
Current: 50 to 100 mA
ANALOG OUTPUT
Current: (short circuit protected)
Impedance: 50 ohms
Voltage: 0-10 VDC
SWITCHED OUTPUT
Opto-Isolated
Load Current: 80 mA maximum AC or DC
Load Voltage: 30V rms, 42.4V peak
On Resistance: 1 ohms minimum / 8 ohms maximum
Switch Point Hysteresis: see application variations
SAMPLING FREQUENCY
>5 KHz
ENVIRONMENTAL
ENCLOSURE RATINGS
Sensor:
IP 67
Electronics: IP 67
OPERATING TEMPERATURE RANGE
Sensor and cable: 32°F to 158°F 0C to 70°C)
Electronics: 32°F to 131°F (0°C to 55°C)
STORAGE TEMPERATURE RANGE
Sensor and cable: -40°F to 185°F (-40°C to 85°C)
Electronics: -40°F to 158°F (-40°C to 70°C)
