Appendix – UPS Components and Options
36
Smart-UPS® VT 10-30kVA, 200/208V and XR Battery Enclosure Operation Guide
990-2359A
Stabilizing Bracket
Always install the Stabilizing Brackets on the 352mm Enclosure (shipped with the UPS) to enhance
the stability of the Enclosure.
If the Enclosure needs to be moved after Stabilizing Brackets have been attached to the Enclosure,
the Stabilizing Brackets must be pushed up into their high position.
Loosen the two screws of both Stabilizing Brackets, and push the bracket up into the high
position.
When the Enclosure has reached its new position, push the Bracket into its “down” position
again, and tighten the screws.
Attach the Stabilizing Bracket to the UPS Enclosure re-using the screws used to secure
the UPS to the pallet during shipment.
WARNING!
For stability reasons, do not remove Stabilizing Brackets from 352mm Enclosures.
Stabilizing
Bracket
