Page 24
Dwyer DLI-P
F3 = PRESS: first highlights and then changes the viewing options of the
pressure channel
F4 = MORE: moves on to Display Confi guration screen
CANCEL= return to Display Confi guration Menu
OK = moves on to Display Confi guration screen
UP = once channel parameter configuration tab is highlighted scrolls
through available options
DOWN = once channel parameter configuration tab is highlighted scrolls
through available options
6.13 Display Confi guration:
Allows the user to change the contrast of the LCD display as well as the channel
size.
F1 = CNTRST: highlights the contrast parameter confi guration tab
F2 = SIZE: highlights and then changes options of the channel size parameter
F3 = MORE: moves back to the Adjust Visibility screen
F4 = EXIT: returns to Display Confi guration Menu
CANCEL = returns to Device Confi guration Menu
OK = moves back to the Adjust Visibility screen
UP = when contrast parameter confi guration tab is highlighted increases
contrast value
DOWN = when contrast parameter confi guration tab is highlighted increases
decreases contrast value
