Crystal DTG - Manual (Page 7)

C R Y S T A L
engineering corporation
PN: 2646 REV B, 8/2002
Firmware Release 1.05
Page 7 of 8
Power
Batteries: 3 x AA, alkaline recommended
Battery Life: 1500 hours continuous operation
Low Battery Indicator: Battery Icon
Dead Battery Indication: “batt”
Connection
Pressure Fitting: ¼
″ male NPT with integral
1 /
16
″ NPT stainless steel filter.
Enclosure
Dimensions: See Below
Weight: 635g (22oz.), including batteries.
Accessories
RS-232 interface adapter kit (PN: 2746)
Duplex (Pressure & Vacuum) Handpump: -13.7 to 500 PSI (PN: 1919)
Hydraulic Handpump: 0 to 5000 PSI (PN: 2820)
Replacement parts
The only user-replaceable parts are the batteries and the 1 /
16
″ NPT stainless steel filter.
HI
LO
units peak peak
HI
units
LO
units
D I G I T A L T E S T G A U G E
peak
zero
on
off on
off
zero
C R Y S T A L
reset
HI
units
D I G I T A L T E S T G A U G E
units peak
zero
on
off on
off
zero
C R Y S T A L
peak
reset
HI
LO
engineering corporation engineering corporation
units
