Specifications, Electrical, Environmental – Crystal WT Series Panel Mount Digital Pressure Gauge User Manual
Page 5: Power

Specifications
5
XP2i External Power Supply Operation Manual
Specifications
—
electrIcal
AC Input Voltage . . . . . . . . . . . . . . . . . 90 VAC to 264 VAC
AC Input Frequency . . . . . . . . . . . . . . 47Hz to 63Hz
AC Input Current . . . . . . . . . . . . . . . . . 0.5Arms (120VAC), 0.25Arms (240VAC)
AC Inrush Current (Cold) . . . . . . . . . 30A max. (120VAC), 60A max. (240VAC)
AC Surge Immunity . . . . . . . . . . . . . . IEC 61000-4-5, Level 3
—
enVIronmental
temperature
Operation . . . . . . . . . . . . . . . . . . . . . . . 0 to 35° C
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . -25 to 85° C
Humidity . . . . . . . . . . . . . . . . . . . . . . . . 10% to 90% RH (Non-condensing)
Emissions . . . . . . . . . . . . . . . . . . . . . . . . FCC Class B, EN 55022 B
Immunity, EN 50082-1 . . . . . . . . . . . 61000-4-2, Level 3
61000-4-3, Level 2
61000-4-4, Level 2
61000-4-3, Level 2
—
power
Power On Indicator . . . . . . . . . . . . Green LED
DC Output Cord/Connector . . . . 1.8 meter (70.8 inches)
2.1mm x 5.5mm Coaxial Plug, Center Positive
!
WARNING: do not operate serial interface within a hazardous atmosphere.
