TABLE OF CONTENTS
SECTION HEADING PAGE
1 Introduction 2
2 Specifications 2
3 C-1500N Features 3
4 How to install the C-1500N 3
4.1 Mounting location 3
4.2 Electrical connections 5
4.3 How to install the tubing and fittings 6
5 How to operate the C-1500N 8
5.1 Adjusting the Pump Output - Standard Models 8
5.2 Adjusting the Pump Output - Fixed cycle timer Models 9
5.2 Measuring the pump’s output - volumetric test 9
6 How to maintain the C-1500N 9
6.1 Routine inspection and cleaning 9
6.2 How to clean the C-1500N 9
1.0 Introduction
Thank you for purchasing the C-1500N positive displacement metering pump.
The C-1500N is designed to inject chemicals into piping systems. All models are
equipped with a top mounted mechanical flow rate adjustment knob. Optional
on/off cycling timers are available.
The pump has been tested by NSF International for use with 12-½% Sodium
Hypochlorite.
CAUTION: This pump has been evaluated by ETL Intertek Testing Services for
use with water only. The factory performance tests the pump with water only.
2.0 Specifications
Maximum Working Pressure
125 psig / 8.6 bar*
o o Maximum Fluid Temperature 130 F / 54 C
o Output Accuracy +/- 10% of maximum (water @ 70 F, 0
psig, and 5’ suction lift)
o o Ambient Temperature Range 14 to 110 F / -10 to 43 C
Enclosure NEMA 3R (IP 23) acceptable for outdoor
use
Duty Cycle Continuous
Maximum Viscosity 1,000 Centipoise
Maximum Suction Lift up to 10 ft. water
Power Requirements 115V60Hz 45 Watts
220V50Hz 45 Watts
230V60Hz 45 Watts
24V60Hz 45 Watts
Dimensions 9-1/16” high x 4-1/2” wide x 5-3/4” deep
Weight 7 lb.
C-1500N Page 2
