Item Part No Description Qty
C-1500N PARTS LIST
1 C-535A6-6 Pumphead Kit, HDN Viton 1
C-535A6-6E Pumphead Kit, HDN EP 1
7 71000-324 FootValve S/A, C-340V, VT 1
71000-325 FootValve S/A, C-340E, EP 1
8 90008-068 Ceramic weight, C-346 1
9 70004-074 Cover P/Head, HD Chem-Feed logo 1
70004-071 Cover P/Head, HD Noir logo 1
70004-086 Cover P/Head, HD Micro logo 1
10 90011-141 Screw 10-32 x 1.25 4
11 70000-638 Tube Indicator Glass 3/8 x 5FT 1
76000-171 Tube Suction 1/4 x 5FT 1
12 90002-077 Tube Nut, .25T, P.P. 2
90002-047 Tube Nut, .37T, P.P. 2
13 71000-204 Adapter S/A Bullet .37T Viton 2
71000-205 Adapter S/A Bullet .37T EP 2
71000-224 Adapter S/A Bullet .37T Silicon 2
71000-225 Adapter S/A Bullet .25T Viton 2
71000-226 Adapter S/A Bullet .25T EP 2
71000-227 Adapter S/A Bullet .25T Silicon 2
14 71000-195 Cartridge Bullet Valve S/A, Double-Ball 2
15 90002-146 P/Head Noir Molded, P.P. 1
16 76000-168 Tubing D/Charge, 3/8 x 5FT 1
76000-169 Tubing D/Charge, 1/4 x 5FT. 1
17 70000-683 Diaphragm S/A 2.0 15N, Viton/TFE 1
70000-682 Diaphragm S/A 2.0 15N, EP/TFE 1
71000-058 Diaphragm S/A 1.6 15N, Viton/TFE 1
71000-057 Diaphragm S/A 1.6 15N, EP/TFE 1
18 90006-006 Return Spring 2
19 76000-172 Stirr-up 1
20 90002-001 Slide Bearing 2
21 90001-132 Offset Cam #1 .125” 1
90001-133 Offset Cam #2 .055” 1
90001-134 Offset Cam #3 .187” 1
90001-141 Offset Cam #4 .100” 1
22 90002-017 Dial Knob 1
24 90011-168 Screw #6 x .62 PH oval ‘A’ 4
25 C-1503N-3 Top Cover Assembly with bearing 1
29 70000-131 Drive Cam S/A #1 .125” 1
70000-133 Drive Cam S/A #2 .055” 1
70000-132 Drive Cam S/A #3 .187” 1
70000-722 Drive Cam S/A #4 .100” 1
C-1500N Page 11
