TABLE OF CONTENTS
SECTION HEADING PAGE
1 Introduction 2
2 Specifications 2
3 Features 3
4 How to install the metering pump 3
4.1 Mount Location 4
Installation 5
4.2 Electrical connections 6
4.3 How to install the tubing and fittings 7
5 How to operate the metering pump 9
5.1 Adjusting the Pump Output - Standard Models 9
5.2 Adjusting the Pump Output - Fixed cycle timer Models 9
5.3 Measuring the pump’s output - volumetric test 10
6 How to maintain the metering pump 10
6.1 Routine inspection and cleaning 10
6.2 How to clean the metering pump 10
Exploded View (C-600HV) 11
Exploded View (C-600P) 13
1.0 Introduction
Thank you for purchasing the positive displacement metering pump.
The pump is designed to inject chemicals into piping systems.
All models are equipped with a top mounted mechanical flow rate
adjustment knob. Optional on/off cycling timers are available.
2.0 Specifications
Maximum Working Pressure
125 psig / 8.6 bar* (C-600P)
20 psig 1. 37 bar* (C-600HV)
o o Maximum Fluid Temperature 130 F / 54 C
Output Accuracy +/- 10% of maximum
o (water @ 70 F, 0 psig, and 5’ suction lift)
o o Ambient Temperature Range 14 to 110 F / -10 to 43 C
Enclosure Zinc - Metal
Duty Cycle Continuous
Maximum Viscosity 1,000 Centipoise
Maximum Suction Lift up to 10 ft. water
Power Requirements 115V60Hz 45 Watts
220V50Hz 45 Watts
230V60Hz 45 Watts
24V60Hz 45 Watts
Dimensions 6-1/2” H x 6-1/2” W x 5-3/4” D (C-600P)
7”H x 6-3/4” W x 6-1/8” D (C-600HV)
Weight 8 lb.
**Depending on Model number
Page 2 C-600
