Blue-White C-600P CHEM-FEED Diaphragm Pump User Manual
Page 12
Catalog No.
Description
Amount Reqd.
1.
C-3391-10
Injection Fitting
1
2.
C-3330
Clamp
4
3.
C-334-10
Tubing 5/8” O.D. , 5FT
2
4.C-428-10
Top Adaptor, 5/8” Tube
1
5.
90003-033
O-ring (EP) (Viton)
1
6.
C-354-2
Spring
1
7.
C-926E
Check Valve (Hypalon)
1
C-926V
Check Valve (Viton)
1
8.
C-3203
Headblock (Clear) (Polyethylene)
1
9.
C-3504
Screw, (Headblock) #8-32X1 1/2
4
10.
C427-10
Bottom Adaptor, 5/8” Tube
1
11.
C-3345C
Lock Nut
1
12.
C-3345C
O-ring
1
13.
C-3373-10
Foot Strainer
1
14.
C-3393-10
Combination Foot Strainer Bulkhead
1
15.
C-3106NH
Diaphragm (Hypalon)
1
C-3106NV
Diaphragm (Viton)
1
16.
90006-526
Aluminum Backup Washer
1
17.
76000-514
H.V. Aluminum Spacer
1
18.
C-3301
Motor Mount
2
19.
C-624
Screw 10-32X1/2
4
20.
C-3325
Cam Set
1
21.
C-3304
Yoke and Bearing
1
22.
90011-155
Screw 6-32X3/8”
1
23.
90002-201
Cam Cover
1
24.
C-618P-60
Gearbox Assembly(60 RPM)
1
C-618P-125
Gearbox Assembly(125 RPM)
1
C-618P-250
Gearbox Assembly(250 RPM)
1
25.
C-612PB
Armature Bearing
2
26.
C-615P1
Motor Winding (115V-60hz)
1
C-615P2
Motor Winding (230V-60hz)
1
C-615P3
Motor Winding (220V-50hz)
1
27.
70000-027
Rotor w/ Spacers
1
28.
C-612F
Armature Fan
1
29.
C-625
Motor Screw 8-32X2 3/4
2
30.
C-608P
Motor Cover (Zinc)
1
C-608P(AL)
Motor Cover (Aluminum)
1
31.
C-628
Cover Screw 6-32 X 2 3/4
2
32.
90007-515
1/2“ Aluminum Chase Nipple
1
33.
C-308J
Junction Box
1
34.
90011-129
Junction Box screw 8-32 X 5/16
2
C - 6 0 0 H V P a r t s L i s t
