M-Series® M1000
Firmware Update Procedure
MAG-UM-00678-EN-01 (April 2014)
Installation Manual
UPDATE PROCEDURE
The firmware update can be ordered with this part number:
67354-011
1. Verify that the currently installed firmware is not newer
than the firmware on the USB memory stick.
2. Power OFF the meter.
3. Plug the USB cable into the micro USB port.
4. Plug the USB memory stick into the USB cable.
5. Power ON the meter.
6. While the firmware updates, the status of the procedure
displays on the screen.
7. Remove the USB cable and USB memory stick when
prompted.
8. When the update is complete, the display returns to the
Main Menu.
9. Verify that the firmware version information is correct.
10. Clear the (T2) totalizer (Main Menu > Totals).
Micro USB Port
