Torque Rating
When using Precision Flow Meters with AN end fittings at high pressure, tighten the fittings to the torque values in
Table 2 .
Size Minimum Torque (Dry)
All CLF Meters 270 in-lb
8-4, 8-6, 08 450 in-lb
10 650 in-lb
12 900 in-lb
16 1200 in-lb
20 1400 in-lb
24 1600 in-lb
32 1800 in-lb
Table 2: Torque values
Materials
Materials listed in
Table 3 are recommended and used for most turbine flow meter applications . For unusual requirements—
such as those outside the range of –300…350° F or those with extremely corrosive liquids—consult the Badger Meter
Sales Department .
Part Type
Bearing Hybrid ceramic
Body 316
C-Washer 302
Hub 303
Locknut CRS (plated)
Pickoff 304
Spacer 303
Spring 302
Snap Ring 303
Straightener Assembly 316
Rotor 17-4 SS
Table 3: Materials per part
Dimensions
•
See “Dimensions (Liquid)” on page 14 for tube sizes and mounting dimensions of liquid Precision Turbine Flow Meters .
• See “Dimensions (Gas)” on page 18 for tube sizes and mounting dimensions of gas Precision Turbine Flow Meters .
