SPECIFICATIONS
Materials of Construction
Body and Internal Wetted Parts
316 stainless steel
Rotor
CD4MCU stainless steel
Bearings
Tungsten carbide
Rotor Shaft
Tungsten carbide
Operating Limitations
Temperature
–150…350° F (–101…177° C)
The meter should not be subjected to temperatures above 350° F (177° C), or below
–150° F (–101° C) or the freezing point of the metered liquid .
Pressure
Varies based on class of ANSI flanges used for mounting . See table below:
Flange Rating (ANSI)
150#
300#
600#
900#
1200#
Working Pressure (psi)
285
740
1480
2220
3705
Working Pressure (MPa)
1 .97
5 .10
10 .2
15 .31
25 .55
*Test Pressure (psi)
427 .5
1110
2220
3330
5557 .5
*Test Pressure (MPa)
2 .95
7 .65
15 .31
22 .96
38 .32
* Test pressure based on 1 .5 safety factor .
Accuracy
± 1 .0% of reading
Repeatability
± 0 .1%
Calibration
Water (NIST Traceable Calibration)
Corrosion
All Blancett Explosion-Proof QuikSert turbine meters are constructed of stainless steel and
tungsten carbide . The operator must ensure that the operating fluid is compatible with these
materials . Incompatible fluids can cause deterioration of internal components and cause a
reduction in meter accuracy .
Pulsation and Vibration Severe pulsation and mechanical vibration will affect accuracy and shorten the life of the meter
Filtration
If small particles are present in the fluid, Blancett recommends that a strainer be installed
upstream of the meter (see
for filtration recommendations) .
Compliance
Class I Div . I Groups C,D
Complies to UL1203 and CSA 22 .2 No . 30
Met Labs File No . E112860
Repair Kit
The Explosion-Proof QuikSert Turbine Flow Meter Repair Kit is designed for easy field service of
a damaged flow meter, rather than replacing the entire flow meter (see
) . Repair parts are constructed of stainless steel alloy and tungsten carbide and are
factory calibrated to ensure accuracy throughout the entire flow range . Each kit is complete and
includes the calibrated K factor which is used to recalibrate the flow monitor or other electronics
to provide accurate output data .
