Status
Indicator
Icon Alarm Description
High Resolution
with ORION
Cellular, Fixed
Network (SE) or
Migratable (ME)
Encoder Protocol
with ORION
Cellular, Fixed
Network (SE) or
Migratable (ME)
RTR with
ORION Fixed
Network (SE) or
Migratable (ME)
Meter
functioning
correctly
Meter operating correctly Normal operation
Indicator not sent
to endpoint
Normal operation
Indicator not sent
to endpoint
Normal operation
Indicator not sent to
endpoint
Meter alarm Several potential conditions may
exist, including:
• Empty pipe: “err” displays on
LCD Alarm clears when pipe
is filled
• Low Temperature limits
exceeded: meter continues to
operate but outside specified
accuracy range Alarm clears
after 35 days unless alarm
condition continues
• Maximum flow rate is exceeded
No consumption is displayed
until back within specified
flow range Both the meter
functioning correctly and the
meter alarm are active
• Other meter or sensor issue:
meter continues to operate if
possible Alarm clears after
35 days unless alarm
condition continues
Consumption
data is sent to the
endpoint Meter
Alarm is also sent
Meter Alarm is sent
to the endpoint
NOTEE: No
consumption data
is sent to endpoint
when the alarm
is active
Consumption
data is sent to the
endpoint, except
when Exceeding
Max Flow Alarm
is set
Reverse flow The meter detects reverse flow
and triggers the reverse flow alarm
icon on the E-Series display The
alarm remains active for 35 days
The alarm automatically clears
after 35 days if the condition has
not recurred
Meter detects
reverse flow
and sends alarm
message to
the endpoint
Meter does not
send the alarm The
endpoint detects
and reports the
reverse flow and
will report the
read exactly how it
is received
No alarm condition
reported by the
endpoint will only
record positive,
forward flow
Suspected
leak
Meter detects 24 hours without
one 15-minute interval of no flow
The alarm clears automatically
when a 15-minute no-flow
interval occurs
Meter detects
suspected leak
and sends alarm
message to
the endpoint
Meter does not send the alarm
The endpoint detects continuous
consumption over 24-hour period and
reports suspected leak
30 day no
usage
No measured flow in past 30 days
The alarm automatically clears
once flow occurs
Meter detects 30
day no usage and
sends alarm to
the endpoint
Meter does not send the alarm
The endpoint detects no change in
consumption over 30-day period and
reports 30 day no usage
End of life
battery
indicator
Indicated battery life based on pre-
calculated consumption Alarm
is activated after 19 years and 6
months and does not clear
Meter sends alarm
to the endpoint
Meter does not send the alarm
