1
INTRODUCTION
Amerex Wheeled Halon 1211 fire extinguishers provide "clean agent" fire fighting capability far
exceeding that achievable with hand portable types. Models 695 (50 lb.) and 600 (150 lb.)are
stored pressure wheeled Halon 1211 liquefied gas extinguishers. Highly effective on Class A
(ordinary combustibles), Class B (flammable liquids) and non-conductive in Class C (energized
electric) hazards. Model 600 may be towed at speeds up to 15 mph over paved surfaces and
can be easily managed by one person.
To provide optimum extinguisher reliability, recharging should be performed by persons trained
in fire extinguisher maintenance and servicing. This manual should be used as a guide for
installing and servicing these Amerex extinguishers. The best place to have your
extinguishers. The best place to have your extinguishers serviced and recharged is your
"Authorized Amerex Distributor" who has the professional experience and equipment to do it
properly.
PREPARING YOUR NEW EXTINGUISHER FOR USE
1. Remove all wrappings, straps and pallet retaining bolts.
2. Examine the extinguisher for shipping damage.
3. Check to insure that the hose connection at the discharge valve and the nozzle connection
to the hose are tight.
4. Check to insure that the shut-off nozzle is in the closed position. The ring (safety) pin
should be installed and the lockwire (tamper) seal intact.
5. Visually inspect the pressure gauge. The pressure gauge should be in the green zone (200
±10 psi range). the method used to determine proper agent fill is by weighing the
extinguisher. The gross weight is marked on each extinguisher nameplate.
NOTE:
Halon 1211 is a liquefied gas that generates its own vapor
pressure. Temperature can affect the pressure gauge reading.
Normal "properly charged" markings are correct for 70°F (21°C.)
Generally, as temperatures go up, pressure readings go up.
THIS MANUAL IS ATTACHED TO EVERY NEW EXTINGUISHER SHIPPED FROM THE FACTORY. IT
CONTAINS VALUABLE INFORMATION WHICH SHOULD BE STUDIED BY EVERYONE WHO WILL USE OR
SERVICE THE EXTINGUISHER. THE MANUAL SHOULD BE STORED IN A CONVENIENT LOCATION FOR
EASY REFERENCE.
AMEREX CORPORATION DOES NOT SERVICE, MAINTAIN OR RECHARGE FIRE EXTINGUISHERS.
THIS MANUAL IS PUBLISHED AS A GUIDE TO ASSIST QUALIFIED SERVICE PERSONNEL IN THE
INSPECTION, MAINTENANCE AND RECHARGE OF AMEREX FIRE EXTINGUISHERS ONLY. NO
INSTRUCTION MANUAL CAN ANTICIPATE ALL POSSIBLE MALFUNCTIONS THAT MAY BE
ENCOUNTERED IN THE SERVICE OF FIRE EXTINGUISHERS. DUE TO THE POSSIBILITY THAT PRIOR
SERVICE PERFORMED ON THIS EQUIPMENT MAY HAVE BEEN IMPROPERLY DONE, IT IS
EXTREMELY IMPORTANT THAT ALL WARNINGS, CAUTIONS AND NOTES IN THIS MANUAL BE
CAREFULLY OBSERVED. FAILURE TO HEED THESE INSTRUCTIONS COULD RESULT IN SERIOUS
INJURY.
AMEREX ASSUMES NO LIABILITY FOR SERVICE, MAINTENANCE OR RECHARGE OF FIRE
EXTINGUISHERS BY PUBLISHING THIS MANUAL.
