JetStream®Air Curtain
Installation Instructions
TOOLS NEEDED:
Pen or Pencil
Drill
Phillips Screwdriver
Tape Measure
Ladder
PART DIMENSIONS
P/N 477258
0511
FOR ANY QUESTIONS OR COMMENTS, PLEASE CONTACT AN ALECO REPRESENTATIVE
2720 E. Avalon Ave. Muscle Shoals AL, 35661 Phone (256) 248-2402 or toll free 1-800-633-3120
Fax: 1-800-750-9616 email: [email protected] web: www.aleco.com
A
I
H
J
B
C
D
E
B
F
G
Part Number
A
B
C
D
E
F
G
H
I
J
475009
36"
11
7/16
"
22"
475010
42"
11
7/16
"
22"
475012
48"
17"
10
5/8
"
17"
475015
60"
22
7/16
"
10
5/8
" 22
7/16
"
8
1/2
"
5
1/4
"
1
3/16
"
2"
5
13/16
"
10
1/8
"
FRONT
SIDE
BACK (
mounting plate is shaded portion
)
CAUTION
: READ CAREFULLY
Do not install unit outdoors
Do not install unit where it can get wet or
near excessive steam or corrosive gases
Use unit at voltage and frequency specified
Never use harsh chemicals to clean the unit
!
ENAMEL COATED AIR CURTAIN DIMENSIONS
Part Number
A
B
C
D
E
F
G
H
I
J
475018
36"
11
7/16
"
22"
475021
42"
11
7/16
"
22"
475024
48"
17"
10
5/8
"
17"
475027
60"
22
7/16
"
10
5/8
" 22
7/16
"
8
1/2
"
5
1/4
"
1
3/16
"
2"
5
13/16
"
10
1/8
"
STAINLESS STEEL AIR CURTAIN DIMENSIONS
If the air curtain is dropped on its side during shipment, the blower wheels may come out of the side bushings. BEFORE
OPERATING be sure to check the blower wheels on the left and right side of the unit! Follow these steps to correct the
problem:
IMPORTANT - PLEASE READ!
1) Unscrew and remove the intake grill on the front and the round end-plate on the side of the unit. 2) Loosen the set screw that holds the blower wheel
on the motor shaft. 3) Remove the rubber bushing from the round end-plate and push onto the round metal bearing that is attached to the end of the
blower wheel. Make sure the rubber bushing is bottomed out on the bearing. 4) Reattach the round end-plate to the unit and then slide the blower wheel
toward the end-plate, pushing the rubber bushing back into the plate. 5) Tighten the set screw to hold the blower wheel on the motor shaft. Reattach the
intake grill.
