Di agram 1
Bar Placement
Diagram 2
Attac h Bar
Diagram 3
Attac h Strips
Clear-Flex ® II
Installation Instructions
Us ing HTP Bu lle t/Lo op Ins t a lla tion Sy s t e m
TOOLS NEE D ED
• Ratchet or Wren ch
• Drill
• Step Stool or Ladd er
• Utility Knife to Cut Strips
1. Cente r and at tach left and right mounting
bra c kets with ¼” lag screws on the in sid e
wall of wal k -i n above do or openi ng 39
3/ 8
”
apart on a lev e l line. Attach lag scre w in
bottom hole o n ly on each b r acket (Dia gram
1).
2. Place mo unti ng bar in b r a c kets a nd in stall
¼” lag screw throug h both the mounting bar
and bracket o n both sid e s and tighten al l
scre ws (Di agram 2).
3. Attach strip s by folding stri p over ba r fro m
behin d and p u shi ng HTP Bullet (sh ade d
gray) th roug h holes (Dia gram 3).
4. Once all of the door strip s have bee n
attache d , the strip s can be trimmed to le ave
¼” of clea ran c e from the fl oor surfa c e. Your
PVC door stri ps may be tri mmed by usi ng a
comm on utility knife to score and then be
torn by hand .
Parts List
(1) L e ft Moun ting Bracket
(1) Right Mou n ting Bra c ket
(1) Mo unting Bar
(4) ¼ ” Lag Screws
(9) 6 ” x .060 Clea r Flex® II Strips
or
(6) 8 ” x .080 Clea r Flex® II Strips
