General specification – Airedale Air Cooled Condensers R407C User Manual
Page 9
CONDENSERS
C11 - 45 / CS50 - 105
Condensers
9
Installation and Maintenance Manual: 6259642 V1.2.0 10/2013
General Specification
MECHANICAL DATA
C45HI
CS50
CS65
CS80
CS105
Total Heat of Rejection
(1)
kW
46.1
51.8
69.3
84.5
111.3
Dimensions - Horizontal
(2)
Height
mm
1048
1167
1167
1167
1167
Width
mm
645
1000
1000
1000
1000
Length
mm
1650
2184
2184
3565
3565
Dimensions - Vertical
(2)
Height
mm
1092
1090
1090
1090
1090
Width
mm
1100
1167
1167
1167
1167
Length
mm
1650
2184
2184
3565
3565
Weight
Machine
kg
110
132
162
208
260
Construction
Material/Colour
Galvanised Sheet Steel, Epoxy Baked Powder Paint - Light Grey (RAL 7035)
Condenser
Air Cooled - Rifled Copper Tube/Turbulated Aluminium Fins
Quantity
1
1
1
1
1
Total Face Area
m²
1.6
2.11
2.11
3.63
3.63
Nominal Airflow
m³/s
4.45
4.8
4.2
7.5
6.6
Discharge
H Horizontal or V Vertical (Please Specify at Order)
Fan & Motor
Axial
Quantity
2
2
2
3
3
Diameter
mm
630
630
630
630
630
Maximum Speed
rpm
900
900
900
900
900
Refrigeration
Single Circuit
Refrigerant Type
R407C
Holding Charge
Inert Gas
Coil Volume
L
15.7
10.7
21.5
18.3
36.7
Refrigerant Charge
(3)
kg
6.1
4.3
8.5
7.3
14.6
Connections
Liquid Line - Sweat
in
7/8
3/4
3/4
7/8
7/8
Discharge Line - Sweat
in
7/8
1 1/8
1 1/8
1 3/8
1 3/8
OPTIONAL EXTRAS
Short Case Axial Fan
Designed to 75 Pa ESP
Dimensions - Horizontal
Height
mm
1048
1167
1167
1167
1167
Width
mm
711
1000
1000
1000
1000
Length
mm
1650
2184
2184
3565
3565
Dimensions - Vertical
Height
mm
1162
1130
1130
1130
1130
Width
mm
1100
1167
1167
1167
1167
Length
mm
1650
2184
2184
3565
3565
Weight
Machine
kg
134
154
184
242
294
(1)
Nominal data based on 35°C ambient and a 50°C mean condensing temperature and using standard fan.
(2)
Overall dimensions for clearance; refer to
Dimensional & Installation Data
(3)
For guidance only.
