Page 14: Standard condenser fan (mm) (c11 shown)
C11-45 / CS50 - 105
CONDENSERS
14
Condensers
Installation and Maintenance Manual: 6259642 V1.2.0 02/2013
Dimensional & Installation Data
DIMENSIONS / MASSES / POSITIONING - VERTICAL
Standard Condenser Fan (mm) (C11 Shown)
(3)
500mm
(2)
(4a)
A
D
1800
(2)
C
E
B
F
500
(2)
500
(2)
500
(2)
500
(2)
(5)
(4b)
(1)
(1)
Optional Short Case Axial Fan (mm) (SCAF) (C45 Shown)
DIMENSIONS (mm)
MASS (kg)
Standard Fan
Optional SCAF
Standard
Fan
Optional
SCAF
A
B
C
D
E
F
F1(6)
A
C11HI-V
997
700
1275
952
630
1118
N/A
1112
51
61
C15HI-V
997
700
1275
952
630
1118
N/A
1112
63
73
C20HI-V
1092
900
1100
952
830
944
N/A
1162
58
70
C25HI-V
1092
900
1100
952
830
944
N/A
1162
65
77
C35HI-V
1092
1100
1650
952
1030
1494
N/A
1162
97
109
C45HI-V
1092
1100
1650
952
1030
1494
N/A
1162
110
134
(1)
Airflow
(2)
Minimum clearances in mm
(3)
8mm fixing points
(4)
Service connections to left hand side of the unit: a = Liquid Outlet, b = Discharge Gas Inlet
(5)
Mains Electric Isolator, (CS50
– CS105 located behind open side panel)
(6)
Additional support to sizes CS80- CS105
(7)
4 lifting eye bolts to unit top, sizes CS50
– CS105
(8)
Optional Short Case Axial Fan with integral duct fixing holes
