Precision Air Conditioning EasiCool™ EZRE
11 EasiCool EZRE Operational Manual 7610207 V1.0.0_02_2013
O
pe
ra
tion
Navigation Sub Menus
There are eight sub menu’s available from the main navigation menu, these are listed below:
1 Unit On/Off Allows the user to switch on or switch off the unit.
2 Maintenance Allows the user to view maintenance related parameters, such as hours run, sensor
calibration and manual overrides.
3 Alarm Log Allows the user to view the alarm log.
4 Input/ Output Allows the user to view the status of the controller inputs and outputs.
5 Clock Allows the user to view the current time, date and day of the week. On/Off and temperature
time zones can also be set.
6 Set point Allows the user to adjust the return air temperature set point.
7 User Allows the user to adjust user related parameters, such as high and low alarm limits and
temperature bands.
8 Manufacturer
Allows the user to enter the manufacturer menu and adjust various manufacturer related
parameters, such as unit configuration and timing settings.
Navigation
Initially, use the
Prg
button to access the main navigation menu, the cursor will appear in the top right hand corner
with the first menu UNIT ON/OFF selected.
Use the and buttons to move to the desired menu.
The selected menu will be shown in BLOCK CAPITALS. Press to enter the selected menu.
