Actuator
Series Action Fail Mode
Flow
Direction
Declutch.
Gear Op. Positioners
Air Filter
Regulators
Special
Options
ASCO
Solenoids
0
None,
Double Act
or Gear Op.
Single Acting
w. Spring
Return
2
4 Sprngs
3
6 Sprngs
4
8 Sprngs
5
10 Sprngs
6
12 Sprngs
ELECTRIC:
M
Modulating
T
On-Off
000
None
Pneu.Rack & Pinion:
073
Size RP73
103
Size RP103
148
Size RP148
222
Size RP222
295
Size RP295
470
Size RP470
586
Size RP586
900
Size RP900
999
Size RP1213
Manual gear op.:
G30
Size GO-30
w. 12” HW
(1 - 4”)
G50
Size GO-
50 w.
12” HW (6”)
G51
Size GO-
50 w.
18” HW (8”)
ELECTRIC
120VAC:
EA3
Size P2
EB3
Size P3
E04
Size P4
E05
Size P5
E06
Size P6
E07
Size P7
0
None or
Gear Op.
PNEUMATIC:
S
Single Act.
Fail Open
T
Single Act.
Fail Closed
D
Double Act.
No Fail
ELECTRIC:
1
20mA to
Close,
Signal
Loss Open
2
20mA to
Open, Signal
Loss Closed
3
20mA to
Close,
Signal
Loss As Is
4
20mA to
Open, Signal
Loss As Is
0
None
1
Flow to
Close
2
Flow to
Open
Note: “0”
Not
Allowed on
Actuated
Valve
0
None
6
Size DG6
(1-3”)
8
Size DG8
(4”)
1
Size DG11
(6 & 8”)
NOTE:
Only for use
as Accessory
to Pneumatic
R&P Actuator.
0
None
B
Type 300,
0-60 PSI
C
Type 300,
0-120 PSI
D
Type 350SS,
0-100 PSI
0 None
120 VAC COILS
C
8320G704
3-Way Brass
D
8320G714
3-Way SS
E
8342G501
4-Way Brass
F
8342G511
4-Way SS
G
8342G502*
4-Way Brass
H
8342G512*
4-Way SS
N
EF8320G704
3-Way EXP Br.
P
EF8320G714
3-Way EXP SS
R
EF8342G501
4-Way EXP Br.
S
EF8342G511
4-Way EXP SS
T
EF8342G502*
4-Way EXP Br.
U
EF8342G512*
4-Way EXP SS
0
None
S
Special Opts
or Set-up
T
SS Tubing
G
SS Tagging
B
SS Tubing
and Tagging
0000
None
PosItioners:
BxP_
BLX Pneumatic
BxE_
BLX ElectroPneumatic
BxI_
BLX ElectroPneu. Intrn. Safe
BxX_
BLX ElectroPneu. Exp.Proof
BxF_
BLX ElectroPneu. Fail Freeze
P24_ Siemens PS2 Electro-
Pneumatic
P2H Siemens PS2 2,3,4 Wire
HART
P2P_ Siemens PS2 PROFIBUS PA
P2F_ Siemens PS2 FOUND.
FIELDBUS
Note: Yellow &
Black raised
beacons are
standard.
Red & Black
is a special order
option for BLX.
0 No Additions
L w/Mech. Lmt
Swtch’s
F w/4-20 Feedback
B w/Swtch’s &
Feedbck
NOTE:
L,F,B not available
for BI , BX.
4th digit spec.
F Full Range Signal,
3-15 PSI or 4-20mA
L Low of Split
Range, 3-9 PSI or
4-12mA
H High of Split
Range, 9-15 PSI or
12-20mA
x digit spec.
Note: Standard pneumatic tubing
is copper. SS tubing “T”is
optional.
SS tagging “G” (Two lines, 24
characters/line) is optional.
SS tubing and tagging
together “B” is optional.
Actuator Orientation “1”, “2”,
or “3” is optional (See page 17
& 18)
Special Options or Set-Up “S”
Use this code to identify
custom bodies, trim, non-
default set ups, etc. not
identified by another code.
The description of the special
option or set-up and complete
process conditions must be
present on the purchase
order.
If your application requires
a special option or set-up
contact us for details.
*Fail Last Position
NOTE: All solenoids are
direct mounted.
