Level COntrols - IOM 200 Vacuum Breaker 200_IOM_RevAa_1112
REBUiLD kiT
FOR TyPE 200 vACUUm BREAkER wiTh REPLACEABLE SEAT AND SiNGLE SPRiNG
SiZE 2 ThRU 12 iNCh
SEE DwG 0200032510
ITEM QTY DESCRIPTION
ITEM QTY DESCRIPTION
1
2
JAMNUT
10
1
DISC RETAINER
2
1
SPRING BUTTON
12
1
GASKET
3
1
SPRING
14
1
DISC HOLDER
5
1
STEM
15
1
DISC
7
1
STEM GUIDE
17
1
SEAT RING
9
1
CONNECTING PIN
REBUiLD kiT
FOR TyPE 200 vACUUm BREAkER wiTh REPLACEABLE SEAT AND DUAL SPRiNG
SiZE 10 & 12 iNCh EFFECTivE DATE: 9/26/2008
SEE DwG 0200032510
ITEM QTY DESCRIPTION
ITEM QTY DESCRIPTION
1
2
JAMNUT
10
1
DISC RETAINER
2
1
SPRING BUTTON
12
1
GASKET
3
1
OUTER SPRING
14
1
DISC HOLDER
5
1
STEM
15
1
DISC
7
1
STEM GUIDE
17
1
SEAT RING
9
1
CONNECTING PIN
18
1
INNER SPRING
