EcoScan CON 5 / TDS 5
5
2.5 Battery Replacement
A “LO” annunciator in the LCD alerts you when battery power is running low.
Replace with the same type as recommended by the manufacturer.
Caution: Power off the meter when changing battery.
2.6 Connecting the Electrode and Temperature Sensor
To connect electrode into meter, align the connector slots with the posts of
meter’s socket and rotate connector clockwise until it locks. Do not force when
connecting. To remove, simply rotate the connector in anti-clockwise direction
until it unlocks, and slide the connector off the socket.
Insert the mini phono jack of temperature sensor into the socket on the meter.
Unplug the phono jack when not in use or you measure Conductivity or TDS
without any temperature compensation.
1420
uS
LO
BNC of
Conductivity
electrode
Phono jack of
Temperature
probe
