User’s Manual

Internet Connection

Select whether or not your DVR is connected to the Internet.

LAN Setup

Select between Auto Configuration and Manual Configuration
for network configuration, and then select the Test button to test
the network configuration you selected.

NOTE: Selecting Auto Configuration allows the DVR to
automatically obtain LAN parameters (IP address, Gateway,
Subnet Mask and DNS Server address). Selecting Manual
Configuration allows you to set up LAN parameters manually.

NOTE: The network configuration you set should be tested by
selecting Test, otherwise the Next button will cannot be selected,
and you cannot move to the next step.

 Use DSL/PPPoE Setup: Selecting the box allows you to set

up the DSL network. Entering the ID and password for DSL
connection is required.

REVO Dashboard Setup I

Select the Next button to start the Dashboard Setup.

REVO Dashboard Setup II

Select New account if you want to create a new Dashboard account,
and select Existing account if you want to use your existing
Dashboard account.
