TECHNICAL DATA
6
25
OPTIBAR P 1010 C
www.krohne.com 06/2014 - 4002622102 - MA OPTIBAR P1010C R02 en
6.3 Measuring ranges with piezoresistive measuring cell
Pressure in bar
Pressure in psi
6.4 Measuring ranges with thin-film measuring cell
Pressure in bar
Pressure in psi
Nominal pressure
(gauge/abs.)
-1...0 0.10 0.16 0.25 0.40 0.60 1 1.6
Max. working pressure
(MWP)
5 0.5 1 1 2 5 5 10
Burst pressure (OPL) 7.5 1.5 1.5 1.5 3 7.5 7.5 15
Nominal pressure
(gauge/abs.)
2.5 4 6 10 16 25 40
Max. working pressure
(MWP)
10 20 40 40 80 80 105
Burst pressure (OPL) 15 25 50 50 120 120 210
Nominal pressure
(gauge/abs.)
-14.5...0 1.45 2.32 3.63 5.80 8.70 14.5 23.2
Max. working pressure
(MWP)
72.5 7.3 14.5 14.5 29 72.5 72.5 145
Burst pressure (OPL) 108.8 21.8 21.8 21.8 43.5 108.8 108.8 217.6
Nominal pressure
(gauge/abs.)
36.3 58.0 87.0 145 232.1 362.6 580
Max. working pressure
(MWP)
145 290 580 580 1160 1160 1523
Burst pressure (OPL) 217.6 362.6 725 725 1740 1740 3046
Nominal pressure
(gauge/abs.)
60 100 160 250 400 600
Max. working pressure
(MWP)
210 600 600 1000 1000 1000
Burst pressure (OPL) 420 1000 1000 1250 1250 1250
Nominal pressure
(gauge/abs.)
870 1450 2321 3626 5800 8700
Max. working pressure
(MWP)
3046 8702 8702 14500 14500 14500
Burst pressure (OPL) 6092 14500 14500 18130 18130 18130
