TECHNICAL DATA
6
21
OPTIBAR P 1010 C
www.krohne.com 06/2014 - 4002622102 - MA OPTIBAR P1010C R02 en
Process connections
Thread Thread ANSI 1/2 NPT-M; thread ANSI 1/4 NPT-M
Thread ISO 228 G1/2, EN 837-1; thread ISO 228 G1/2, 10 mm bore, DIN 3852; thread
ISO 228 G1/4, EN 837-1; thread ISO 228 G1/4, DIN 3852
Electrical connection
Output signal 4...20 mA current output; 2-wire
Power supply Standard: U
b
= 8...32 VDC
Ex i: U
b
= 10 ... 28 VDC
Safety maximum values (Ex i) U
i
= 28 V, I
i
= 93 mA, P
i
= 660 mW, C
i
≈ 0 nF, L
i
≈ 0 μH;
The supply connections have a maximum internal capacity of 27 nF to the housing.
Load R
lmax
≤ (U
b
- U
bmin
) / 0.02 A [Ohm]
Short circuit protection Continuously
Reverse polarity protection In the event of reversed connections there is no damage but also no function.
Ripple 0.05% of URL / 10 V
Electrical connection Connector M16 ISO 4400
Connector M12x1, 4-pin
Cable PUR
Cable PUR with venting
Thread M12, housing 316L
Approvals and certificates
CE The device fulfils the statutory requirements of the EC directives. The manufacturer
certifies that these requirements have been met by applying the CE marking.
Electromagnetic compatibility
(EMC) acc. to EN 61326
EMC Directive: 2004/108/EC
For more information consult the relevant declaration of conformity.
Pressure equipment directive 97/23/EC
Ex Ex Ex Ex
ATEX II 1G Ex ia IIC T4 or II 1D Ex ia T85°C
IECEx Ex ia IIC T4 Ga or Ex ia IIIC T85°C Da
Other standards and approvals Other standards and approvals Other standards and approvals Other standards and approvals
Vibration resistance acc. to
EN 60068-2-6
10g RMS (25...2000 Hz)
Shock resistant (impact)
according to EN 60068-2-27
500g / 1 ms (P
N
≤ 40 bar / 580 psi)
100g / 11 ms (P
N
≥ 60 bar / 870 psi)
