BM 700 Installation and Operating Instructions Page 3
Contents:
page
1 Handling and storage 3
2 Installation 4
2.1 Field assembly 4
2.2 Mechanical installation 5
3 Electrical connection 7
4 Setting the parameters 8
5 Maintenance, error handling 16
6 Safety information 17
7 Technical data (extract) 18
8 BM 700 Level-Radar Type code 19
9 Parameter check list BM 700 21
Appendix 22
Product liability and warranty:
The BM 700 level gauge is designed solely for measuring the level, distance, volume
and reflection of liquids, pastes, slurries, particulate materials and solids.
The BM 700 level gauge does not form part of an overfill protection system as
defined in the WHG (= German water pollution regulation).
Local codes and regulations apply to its use in hazardous areas.
Responsibility as to suitability and intended use of these level gauges rests solely
with the user.
Improper installation and operation of our level gauges may lead to loss of warranty.
In addition, the "General conditions of sale", form the basis of the purchasing
contract.
If you need to return the level gauge to the manufacturer or supplier, please refer to
the information given in Section 5
1 Handling and storage
Safety advice
Depending on the version, the device will weigh between approx. 10 kg and 30 kg.
To carry, use both hands to lift the device carefully by the converter housing. If
necessary, use lifting gear.
When handling the BM 700, avoid hard blows, jolts, impact, etc.
When storing the "Wave-Stick" version, make sure that the device is not placed on its
side on the PTFE antenna, as this may cause the rod to bend.
