Supplementary Documentation

Page 4 of 44

IFC090, IFC090 i with FF

Introduction

IFC090 FF 01/2006

KROHNE Messtechnik GmbH & Co. KG · Ludwig-Krohne-Str. 5 ‚ D-47058 Duisburg

Tel.: 0203-301 309 ‚ Fax: 0203-301389 · E-mail: [email protected]

1 Introduction

These instructions are supplementary to the “Installation and Operating Instructions IFC 090 K / F“. The details

depicted therein, in particular the Safety Information are valid and should be adhered to. The present

Supplementary Instructions provide additional information for the devices when being operated and connected

to a Foundation Fieldbus.

Note: Please set the controller to manual mode before changing parameters of the IFC 090.

The present Supplementary Instruction for the IFC 090 with Foundation Fieldbus- interface, plus a diskette with

the DD and CCF file are included in our scope of supply, in addition to those items delivered for the standard

device.

2 Installation and Operation

2.1

Technical Data IFC090 FF

Hardware

Physical

to IEC 61158-2 and the FISCO model

Bus characteristics:

9... 30 V; 0.3 A max.; 4.2 W max.

Base current

10 mA

FDE

bus with separate fault detection electronics

Fault current

6 mA; (fault current = max. continuous current – base current)

Starting current

lower than the base current

“Ex“ approval

EEx ia IIC T6 or EEx ib IIC/IIB T6 in conformity with the FISCO model

Connection

independent of polarity

Software

DD, CFF File

supplied on diskette, available also in the KROHNE Downlaod Center

Functional blocks

flow [m3/s], integrator 1 [m3], integrator 2 [m3]; units are default units

Operator control

local display and operator interface at device

2.2 Electrical

Connection

of Foundation Fieldbus Devices

Connect the bus cable as shown in the figure.

• Connect the cable cores to terminals D and DI.. Polarity reversal will not have any effect.
• The cable shield should be connected with minimum length to the FE functional ground.
• The equipotential bonding conductor must be connected to the device by connecting it to FE functional

ground.
