CAPAFLUX IFM 5080 K/CAP-EEx and CAPAFLUX IFM 5080 K/CAP i-EEx 18
3 Operation of the signal converter
The compact flowmeters are always equipped with magnet sensors. In that way it is possible to change
the settings of the converter with aid of the magnet-bar without the necessity to open the flameproof
converter housing in the hazardous area.
It must be noted that the IFC 090 i/CAP-EEx versions Ex-i2 and Ex-i3, following menus do not apply.
(see also Sect. 4.4. "Table of settable functions" in the standard "Installation and operating instructions"
of the IFC090 K/F signal converter)
1.01 Æ VALUE P
1.06 Output/input B1
1.07 Output/input B2
1.06 PULS B1
1.06 STATUS B1
1.07 STATUS B2 1.06 CONTROL B1
1.07 CONTROL B2 3.02 Æ VALUE P
3.07 HARDWARE
Fct. Text Description and settings
1.00 1.00 OPERATION Operations menu
1.01 FULL SCALE ...
Æ VALUE P
1.06 Output/Input B1
1.07 Output/Input B2
1.06 PULS B1
1.06
1.07 STATUS B1
STATUS B2
1.06
1.07 CONTROL B1
CONTROL B2
3.00 3.00 INSTALL. Installation menu
3.02 FLOWMETER ...
Æ VALUE P
3.07 HARDWARE
As a consequence, the chapters included in the standard Installations and operating instructions, giving
detailed descriptions of these menus, must be skipped.
4 Maintenance
The IFM 5080 K/CAP/…-EEx electromagnetic compact flowmeters are maintenance free with regard to
the flowmetering properties. Within the scope of the periodical inspections, which are required for
electrical apparatus that are installed and used in hazardous classified locations, it is recommended to
check the flameproof enclosure on signs of damage or corrosion. This concerns the converter housing
and the primary head housings.
