KROHNE PROFIFLUX IFS 5000 EN - Manual (Page 2)

2
Contents
System description 2
Product liability and warranty 2
Standards and approvals 2
Items included with supply 3
1 Important information for installation: PLEASE NOTE 4-5
2 Suggestions for installation 5
3 Instrument nameplate 6
4 Flowmeter versions 6
5 Installation in the pipeline 7
6 Torques 8
7 Grounding 8-9
8 Replacement of separate primary head IFS 1000 F 10
9 Spares and order numbers 10
10 Technical data 11
11 Dimensions and weights 12-13
Notes 14
Printed form to accompany flowmeters returned to Krohne 15
System description
PROFIFLUX electromagnetic flowmeters are precision measuring instruments designed for the
linear flow measurement of process liquids.
The process liquids must be electrically conductive:
≥
0 5
µ
S/cm (
≥
10
µ
S/cm for DN 2.5/ 1 /
10
”)
≥
20
µ
S/cm for demineralized cold water
The full-scale range Q
100%
can be set as a function of the meter size:
DN 2.5 - 100 / 1 /
10
” - 4” Q
100%
= 0.01 - 340 m 3 /hr = 0.03 - 1500 US Gal/min
This is equivalent to a flow velocity of 0.3 - 12 m/s, or 1 - 40 ft/s.
Product liability and warranty
PROFIFLUX electromagnetic flowmeters are designed solely for measuring the volumetric
flowrate of electrically conductive, liquid process products.
Special codes and regulations apply to their use in hazardous locations, and these are referred to
in the special “Ex” installation and operating instructions (supplied only with hazardous-duty
equipment).
Responsibility as to suitability and intended use of these electromagnetic flowmeters rests solely
with the operator.
Improper installation and operation of the flowmeters (systems) may lead to loss of warranty.
In addition, the “General conditions of sale” forming the basis of the purchase contract are
applicable.
If PROFIFLUX flowmeters need to be returned to Krohne, please note the information given on
the last-but-one page of this manual. Krohne regret that they cannot repair or check your
flowmeter(s) unless accompanied by the completed form sheet.
Standards and approvals
Please refer to the installation and operating instructions for the signal converter.
