DEVICE DESCRIPTION
2
13
OPTITEMP TRA/TCA
www.krohne.com 10/2010 - 4001087001 - Ex AD OPTITEMP TRA/TCA R02 en
2.7.2 Temperature at process connection (without temperature transmitter)
Maximum permitted temperature at process connection for thermometers without temperature
transmitter in [°C]
Maximum permitted temperature at process connection for thermometers without temperature
transmitter in [°F]
DANGER!
The maximum permitted temperature at the process connection for all industrial thermometers
is 400°C / 752ºF.
Thermometer models T
a
= 40ºC T a = 60ºC T
a
= 80ºC T
a
= 100ºC
TxA-S11, threaded thermometer, neck pipe length ≤ 80mm 182 155 127 100
TxA-S12/41, threaded thermometer, neck pipe length ≥ 80mm 400 400 312 100
TxA-P10/40, insert thermometer with thermowell TxA-P10,
neck pipe length ≤ 80mm 323 248 174 100
TxA-P10/40, insert thermometer with thermowell, neck pipe
length ≥ 80mm 400 400 290 100
TxA-P14, insert thermometer without thermowell, neck pipe
length ≤ 80mm 323 248 174 100
TxA-P14, insert thermometer without thermowell, neck pipe
length ≥ 80mm 400 400 290 100
TxA-F13/42, flange thermometer, neck pipe length ≥ 80mm 400 400 339 100
Thermometer models T
a
= 104ºF T
a
= 140ºF T
a
= 176ºF T
a
= 212ºF
TxA-S11, threaded thermometer, neck pipe length ≤ 80mm 361 311 261 212
TxA-S12/41, threaded thermometer, neck pipe length ≥ 80mm 752 752 594 212
TxA-P10/40, insert thermometer with thermowell TxA-P10,
neck pipe length ≤ 80mm 613 479 345 212
TxA-P10/40, insert thermometer with thermowell, neck pipe
length ≥ 80mm 752 752 554 212
TxA-P14, insert thermometer without thermowell, neck pipe
length ≤ 80mm 613 479 345 212
TxA-P14, insert thermometer without thermowell, neck pipe
length ≥ 80mm 752 752 554 212
TxA-F13/42, flange thermometer, neck pipe length ≥ 80mm 752 752 643 212
