4.6 TT 60 R connection diagram

ATTENTION!

ATTENTION!

ATTENTION!

ATTENTION!
Neither install the transmitter in an area with a potentially explosive atmosphere, nor connect it
to a sensor in an area with a potentially explosive atmosphere!

1

Input

2

ProfiBus PA

®

terminator

3

ProfiBus PA

®

output, bus lines

4

Bus feed unit / segment
coupler

Figure 9: TT 60 R connection diagram
