02/2011 – 4000753501 – MA OPTITEMP TT31CR R01 en

www.krohne.com

13

4.4 Connection diagram TT 31 R

ATTENTION!

The transmitter must be installed in a safe area. The measuring input may be connected

to sensors in an area with a potentially explosive atmosphere.

Figure 4: TT 31 R connection diagram

1

Output, channel 2

5

Input, channel 1

2

Output, channel 1

6

Input, channel 2

3

PC connection, channel 2

7

Output signal

4

PC connection, channel 1

8

Test circuit

9

Area with potentially explosive

atmosphere
