2 - 6 2 - 6 2 - 6 2 - 6 2 - 6 C h a p t e r 2 : I n s t a l l a t i o n C h a p t e r 2 : I n s t a l l a t i o n C h a p t e r 2 : I n s t a l l a t i o n C h a p t e r 2 : I n s t a l l a t i o n C h a p t e r 2 : I n s t a l l a t i o n
2.3.2 2.3.2 2.3.2 2.3.2 2.3.2 Configuring the LAN controller Configuring the LAN controller Configuring the LAN controller Configuring the LAN controller Configuring the LAN controller
Before you can establish connection to the ASMB-LE board, you must
configure the LAN port for server management being used by the remote
server to connect to the local/central server.
To configure the LAN port of the remote server:
1. On the prompt, type a s m c - t c o e n a b l e a s m c - t c o e n a b l e a s m c - t c o e n a b l e a s m c - t c o e n a b l e a s m c - t c o e n a b l e, then press . The
screen displays the auto-detected information including the
motherboard name, vendor-device code, and the physical address
(MAC) of the remote server.
A:\>asmc -tco enable
Detect MotherBoard
-> (PSCH-LR)
Detect KCS Interface
Bus Dev Fun Vendor-Device MAC
======== ====== ======= ====== ============== ===================
PSCH-LR 01 01 00 8086 - 1075 00-11-2F-0F-A2-21
Please shutdown the system (Standby power) to enable TCO mode!
A:\>
ASMC Help Menu options ASMC Help Menu options ASMC Help Menu options ASMC Help Menu options ASMC Help Menu options
O p t i o n s O p t i o n s O p t i o n s O p t i o n s O p t i o n s D e s c r i p t i o n D e s c r i p t i o n D e s c r i p t i o n D e s c r i p t i o n D e s c r i p t i o n
-flash -save filename Save the current firmware to a file
-flash -load filename Update the ASMB-LE firmware
-i2c_read bus_num dev_num offset Send the read I 2 C command
-i2c_write bus_num dev_num offset data Send the written I 2 C command
-sdr -save filename Save the SDR data to file
-sdr -load filename Update the SDR data from file
-kcs[smic/bt/pci_smic] NetFn command data.... Send IPMI command
-tco enable[disable] Enable or disable TCO mode
-bmc_ip ip_addr[10.10.10.20] Write the BMC IP address
-bmc_mac Auto-write the BMC MAC addresses
-pet_ip_mac ip_addr[10.10.10.20] mac_addr[010203040506] Write the PET destination IP and
MAC addresses
-bmc_info Displays the BMC and PET IP and MAC
addresses
2. Shutdown the remote server, then disconnect the power plug from the
electrical socket to enable the TCO mode.
3. Restart the remote server from the support CD.
The TCO (Total Cost Ownership) interface for Intel ® Fast Ethernet and
Gigabit LAN controllers allows you to manage the remote server system
even when its operating system is not fully functional.
