Specifications D
Capacities Premises Equipment 206 Module Extension Jack
■
24 Centrex lines via line jacks on
■
2 Centrex lines
■
Maximum 2 devices per extension jack,
four 206 and four 400 modules
■
6 extensions total REN on jack not to exceed 2.0*
■
24 extensions via extension jacks on 2 devices require AT&T 267F2 bridging
four 206 modules adapter. MLS- or MLC-model phone REN:
400 Module 0 (zero)
■
1 loudspeaker paging system via
4 Centrex lines ■
No more than one MLS- or MLC-model
PAGE jack on primary processor phone per jack
module
■
1 audio source via Music-on-Hold For programming, an MLS display phone
jack on primary processor module must be connected to extension jack 10 or
(RCA phono plug required) 11.
■
1 call reporting device via SMDR
jack on primary processor module
(355A/F adapter required)
■
2 doorphones (2 extension jacks)
Dimensions
■
Primary Proc. Mod. 11”(D) x 17”(H) x 1.5”(W) or 27.9 x 43.2 x 3.8 cm 4.0 lbs or 1.8 kgs
and Weights
■
Exp. Proc. Mod. 11”(D) x 17”(H) x 1.5”(W) or 27.9 x 43.2 x 3.8 cm 4.0 lbs or 1.8 kgs
(approx.)
■
206 module 11”(D) x 17”(H) x 1.5”(W) or 27.9 x 43.2 x 3.8cm 4.5 lbs or 2.0 kgs
■
400 module 11”(D) x 17”(H) x 1.5”(W) or 27.9 x 43.2 x 3.8 cm 4.0 lbs or 1.8 kgs
■
Backplane & cover 12”(D) x 19”(H) x 11”(W) or 30.5 x 48.3 x 27.9 cm 5.5 lbs or 2.5 kgs
■
MLS-34D phone 9.7”(D) x 5.3”(H) x 10”(W) or 24.6 x 13.5 x 25.4 cm 2.9 lbs or 1.3 kgs
■
MLS-12D phone 9.5”(D) x 5”(H) x 6.75”(W) or 24.1 x 12.7 x 17.1 cm 1.8 lbs or 0.8 kgs
■
MLS-12 phone 9.5”(D) x 5”(H) x 6.75”(W) or 24.1 x 12.7 x 17.1 cm 2.0 lbs or 0.9 kgs
■
MLS-6 phone 9.5”(D) x 5”(H) x 6.75”(W) or 24.1 x 12.7 x 17.1 cm 2.1 lbs or 1.0 kgs
■
MLC-6 phone 9.4”(D) x 3.4”(H) x 7”(W) or 23.9 x 8.6 x 17.8 cm 2.6 lbs or 1.2 kgs
■
Full digital, nonblocking
Local Phone
■
FCC registration number (U.S): AS5 USA-61630-KF-E
Company DOC registration number (Canada): 230 3756
Information
■
REN (outside line jack): 0.9A per line jack
■
Jack type: RJ11C
■
Loop start lines
Extension
■
Ringing voltage: +5VDC, -140 VDC peak to peak; trapezoidal wave shaping
Jack
■
35- to 38-Volt talk battery
■
Ringing frequency: 20 Hz
Switch Fabric
*The two devices combined on an extension jack can be an MLS- or MLC-model phone with a standard device, or two standard devices;
DO NOT connect two MLS- or MLC-model phones to the same extension jack. If a device lists two RENs, use the higher number when
adding up RENs.
