6.8.2 Process input filter and self test parameters
41010 1010 set counter Cnt2 or read Cnt2 set counter Cnt2 or read Cnt2 set counter Cnt2 or read Cnt2 set counter Cnt2 or read Cnt2 [m 3 ] or [kg] C3.2.7 float 2
41012 1012 no function float 2
41014 1014 no function float 2
41016 1016 no function float 2
41018 1018 preset counter 1 preset counter 1 preset counter 1 preset counter 1 [m 3 ] or [kg] C3.1.5 float 2
41020 1020 preset counter 2 preset counter 2 preset counter 2 preset counter 2 [m 3 ] or [kg] C3.2.5 float 2
41022 1022 no function float 2
Modbus protocol
address Description and settings Converter Fct.
No. Type Number of
registers
1st 2nd
Modbus protocol
address Description and settings Converter Fct.
No. Type Number of
registers
1st 2nd
42000 2000 flow direction flow direction flow direction flow direction
0 = normal direction
1 = reverse direction
C1.2.2 byte 1
42001 2001 pulse filter pulse filter pulse filter pulse filter
0 = off
1 = on
2 = automatic
C1.2.4 byte 1
42002 noise filter noise filter noise filter noise filter
0 = off
1 = on
C1.2.7 byte 1
42003 2003 empty pipe empty pipe empty pipe empty pipe
0 = off
1 = conductivity
2 = cond. + empty pipe (S)
3 = cond. + empty pipe (F)
4 = cond. + empty pipe (I)
C1.3.1 byte 1
42004 2004 no function byte 1
42005 2005 no function byte 1
42006 2006 no function byte 1
42007 2007 no function byte 1
42008 2008 no function byte 1
42009 2009 electrode noise electrode noise electrode noise electrode noise
0 = off
1 = on
C1.3.13 byte 1
42010 2010 settling of field settling of field settling of field settling of field
0 = off
1 = on
C1.3.16 byte 1
42011 2011 diagnosis value diagnosis value diagnosis value diagnosis value
25 = off
31 = electrode noise
8 = terminal 2 DC
9 = terminal 3 DC
C1.3.17 byte 1
43000 3000 limitation low limitation low limitation low limitation low [m/s] C1.2.1 float 2
