I N S T R U C T I O N S H E E T
RAB 39-40FMP
KEPCO
An ISO 9001 Company.
RAB 39-40MRW
RAB 39-40KRW
RAB 39-40RKW3
RAB 39-40RTW
INSTALLATION INSTRUCTIONS
MOUNTING BRACKET
DESCRIPTION (Refer to Figure 1)
The Kepco Models RAB 39-40FMP, RAB 39-40KRW, RAB 39-40MRW, RAB 39-40RKW3 and RAB 39-40RTW each
consist of a mounting bracket and associated hardware. They are used to mount Kepco Series FCP, FMP, KRW,
MRW, RKW (300W) or RTW power supplies to Kepco Model RA 39 and RA 40 Rack Adapters. (RKW 50, 100, 150
and 600 watt models require mounting bracket Model RAB 40-RKW6). The mounting bracket is identical for all mod-
els, however different holes are used to mount the power supply to the bracket.
INSTRUCTIONS
RAB 39-40FMP This bracket can be used for either FCP or FMP power supplies. Attach FCP or FMP power supply
to mounting bracket using “D” holes and hardware indicated in Table 1 (see Table 2 and Figure 1 for location). Attach
mounting bracket to rack adapter using holes marked “C” in Figure 1.
RAB 39-40MRW Attach MRW power supply to mounting bracket using “A” and “B” holes and hardware indicated in
Table 1 (see Table 2 and Figure 1 for location) and hardware supplied with RCW power supply. Attach mounting
bracket to rack adapter using holes marked “C” in Figure 1.
RAB 39-40KRW Attach KRW power supply to mounting bracket using “A” holes and hardware indicated in Table 1
(see Table 2 and Figure 1 for location). Attach mounting bracket to rack adapter using holes marked “C” in Figure 1.
RAB 39-40RKW3 Attach RKW 300W power supply to mounting bracket using “A” holes and hardware indicated in
Table 1 (see Table 2 and Figure 1 for location). Attach mounting bracket to rack adapter using holes marked “C” in
Figure 1.
RAB 39-40RTW Attach RTW 50, 100, 150 and 300W power supply to mounting bracket using “A” holes and hard-
ware indicated in Table 1 (see Table 2 and Figure 1 for location). Attach mounting bracket to rack adapter using
holes marked “C” in Figure 1.
TABLE 1. PARTS LIST
PARTS SUPPLIED
ITEM
KEPCO P/N
PART
FUNCTION
Mounting bracket
Mount FCP. FMP, KRW, MRW or RTW power
supply to RA 39 or RA 40 rack adapter
(1) Bracket
128-2072
(4) Speed Nuts (installed on
bracket)
102-0097
Hardware (power
supply to mounting
bracket)
Hardware to attach FCP, FMP, KRW, MRW
or RTW power supply to mounting brackets.
See Table 2.
See Table 2.
Hardware (mounting
bracket to rack
adapter)
Hardware to attach mounting brackets to RA
39 or RA 40 rack adapter
(4) Machine Screws (6-32 x 1/2)
101-0343
(4) Flat Washers (#6)
103-0028
(4) Int. Lock Washers (#6)
103-0015
