I N S T R U C T I O N S H E E T
RAB 39-40ERD
KEPCO
KEPCO, INC. " 131-38 SANFORD AVENUE " FLUSHING, NY. 11352 U.S.A. " TEL (718) 461-7000 " FAX (718) 767-1102
http://www.kepcopower.com " email: [email protected]
An ISO 9001 Company.
RAB 39-40FAW
RAB 39-40RCW
RAB 39-40RKW6
RAB 40-RKE
INSTALLATION INSTRUCTIONS
MOUNTING BRACKET
DESCRIPTION (Refer to Figure 1)
The Kepco Models RAB 39-40ERD, RAB 39-40FAW, RAB 39-40RCW, RAB 39-40RKW6 and RAB 40-RKE each
consist of a mounting bracket and associated hardware. They are used to mount Kepco Series ERD, FAW, RCW
(350 watt) and RKW (30 watt, 50 watt, 100 watt, 150 watt and 600 watt) power supplies to Kepco Model RA 39 and
RA 40 Rack Adapters. RAB 39-40RCW, and RAB 40-RKE are used to mount RCW 750W and RKW 1500W power
supplies to RA 40 Rack adapters. (RCW 1500 watt models require mounting bracket Model RAB 40-RCW1500;
RKW 300 watt models require mounting bracket Model RAB 39-40RKW3). The mounting bracket is identical for all
models, however different holes are used to mount the power supply to the bracket.
INSTRUCTIONS
RAB 39-40FAW
Attach FAW power supply to mounting bracket using “A” holes and hardware indicated in Table 1
(see Figure 1 for location). Attach mounting bracket to rack adapter using holes marked “D” in Figure 1.
RAB 39-40ERD Attach ERD power supply to mounting bracket using “B” holes and hardware indicated in Table 1
(see Figure 1 for location). Attach mounting bracket to rack adapter using holes marked “D” in Figure 1.
RAB 39-40RCW Attach RCW power supply (350W or 750W) to mounting bracket using “C” holes and hardware
indicated in Table 1 (see Figure 1 for location) and hardware supplied with RCW power supply. Attach mounting
bracket to rack adapter using holes marked “D” in Figure 1. Note that RCW 750W mounts only to RA 40.
RAB 39-40RKW6 Attach RKW power supply to mounting bracket using “B” and “C” holes and hardware indicated in
Table 1 (see Figure 1 for location). Attach mounting bracket to rack adapter using holes marked “D” in Figure 1.
RAB 40-RKE Attach RKE 1500W power supply to mounting bracket using “B” holes and hardware indicated in Table
1 (see Figure 1 for location). Attach mounting bracket to RA 40 rack adapter using holes marked “D” in Figure 1.
TABLE 1. PARTS LIST
PARTS SUPPLIED
ITEM
KEPCO P/N
PART
FUNCTION
Mounting bracket
Mount ERD, FAW, RCW, RKE or RKW power
supply to RA 39 or RA 40 rack adapter
(1) Bracket
128-1838
(4) Speed Nuts (installed on
brackets)
102-0097
Hardware (power
supply to mounting
bracket)
Hardware to attach ERD, FAW, RCW, RKE
or RKW power supply to mounting bracket.
See Table 2.
See Table 2.
Hardware (mounting
bracket to rack
adapter)
Hardware to attach mounting bracket to RA
39 or RA 40 rack adapter
(4) Machine Screws (6-32 x 1/2)
101-0343
(4) Flat Washers (#6)
103-0028
(4) Int. Lock Washers (#6)
103-0015
