KEPCO KIT 219-0527, Cable Kit - BOP 26600, 2 in Series - Manual (Page 2)

KEPCO, INC. 131-38 SANFORD AVENUE FLUSHING, NY. 11355 U.S.A. TEL (718) 461-7000
FAX (718) 767-1102 email: [email protected]
2
228-1633 REV 3 051412
TABLE 2. GENERAL SPECIFICATIONS FOR TWO (2) BOP 26600 UNITS (SERIES)
SPECIFICATION RATING/DESCRIPTION CONDITION
INPUT CHARACTERISTICS
Current
176 Va-c 15A a-c Maximum
264 Va-c 10A a-c Maximum
Leakage current 7mA a-c 230V a-c, 47-63 Hz
OUTPUT CHARACTERISTICS
d-c Output Range E
O Max
±12V d-c
I
O Max
±125A d-c
Closed Loop Gain Voltage Channel 1.2
Current Channel 12.5
Source/sink
adjustment range Voltage –12V to +12V
Current –125A to +125A
Programming
resolution / accuracy Voltage ±18mV
Current ±125mA
Voltage Limit ±18mV linearity ±360mV Full Scale tolerance
Current Limit ±125mA linearity ±2.5A Full Scale tolerance
Readback
resolution / accuracy Voltage Same as individual unit Independent readings for each unit
Current Same as individual unit Independent readings for each unit
Voltage stabilization in voltage mode
Source effect ±6mV Min - max input voltage
Load effect ±12mV 0 to 100% load current
Time effect (drift) ±6mV 0.5 through 24 hours
Temperature effect ±6mV / °C 0° to 50°C
Ripple and noise ±240mV p-p Includes switching noise.
Current stabilization in current mode Same as individual unit
Rise/Fall Time
Voltage 400 µ S/400 µ S
Nominal resistive load, measured from 10 to
90%, 0 to ±100% of rating
Current 500 µ S/500 µ S
Short circuit, measured from 10% to 90%,
0 to ±100% of rating
Frequency bandwidth
Voltage 1KHz
Nominal resistive load, E
OPK
= E
ONOM
,
I
OPK
= I
ONOM
@ 60Hz
Current 800Hz Short circuit, I
OPK
= I
ONOM
@ 60Hz
