KEPCO, INC. 131-38 SANFORD AVENUE FLUSHING, NY. 11355 U.S.A. TEL (718) 461-7000
FAX (718) 767-1102 email: [email protected]
2
228-1523 REV 3
033012
Digital Control (Bitbus) Cable,
(7.5 ft.)
1
Provides communication between master and five slaves comprised of three
series-connected units arranged in 2 parallel branches.
118-1151
Protection Cable (1 ft.)
5
Provides interlock protection signals required for multiple unit operation.
118-1126
Protection - OUT Termination
(Slave)
1
Provides proper termination for the slave connection to the Protection Cable.
195-0108
Protection - IN Termination
(Master)
1
Provides proper termination for the master connection to the Protection Cable.
195-0107
Nut
2
Overcomes tight space for output cable connections. After securing bottom
cable to output terminal stud using one nut, additional cables can be oriented
for best layout and secured with separate nut.
102-0046
Chassis Ground Cable
5
Connects chassis ground terminals of all units.
118-1272
Ground Cable mounting hard-
ware
6 sets
Each set consists of eight parts, mounted in the following order: No. 10 star
lockwasher P/N 103-0106 (at chassis), No. 10 flat washer P/N 103-0031, No.
10 split lockwasher P/N 103-0033, 10-32X3/8 nut P/N 102-0008, No. 10 flat
washer P/N 103-0031, [lug(s) from ground cable], No. 10 flat washer P/N 103-
0031, No. 10 split lockwasher P/N 103-0033, and 10-32X3/8 nut P/N 102-0008.
(See
Purpose
at left for
part
numbers)
Output Sense Cable
4
Connects Output sense terminal to Common sense terminal of next unit.
118-1271
Instruction Manual
1
Lists material supplied and specifications for multiple unit combination.
228-1523
TABLE 3. MODEL PARAMETERS FOR 3 X 2 CONFIGURATION OF SIX (6) IDENTICAL BOP 1000W UNITS
(3 SERIES-CONNECTED UNITS X 2 PARALLEL BRANCHES)
(6) Identical Models
(3 Series x 2 Parallel)
d-c Output Range
Closed Loop Gain
E
O Max
I
O Max
Voltage Channel
(V/V)
Current Channel
(A/V)
BOP 6-125MG
±18V d-c
±250A d-c
1.8
25.0
BOP 10-75MG
±30V d-c
±150A d-c
3.0
15.0
BOP 20-50MG
±60V d-c
±100A d-c
6.0
10.0
BOP 25-40MG
±75V d-c
±80A d-c
7.5
8.0
BOP 36-28MG
±108V d-c
±56A d-c
10.8
5.6
BOP 50-20MG
±150V d-c
±40A d-c
15.0
4.0
BOP 72-14MG
±216V d-c
±28A d-c
21.6
2.8
BOP 100-10MG
±300V d-c
±20A d-c
30.0
2.0
TABLE 4. GENERAL SPECIFICATIONS FOR BOP 1000W 3 X 2 CONFIGURATION
(3 IN SERIES, 2 PARALLEL BRANCHES)
SPECIFICATION
RATING/DESCRIPTION
CONDITION
INPUT CHARACTERISTICS
Current
176 Va-c
57.0A a-c
maximum
264 Va-c
38.4A a-c
maximum
Leakage current
21.0mA a-c
230V a-c, 47-63 Hz
OUTPUT CHARACTERISTICS
Programming
resolution / accuracy
Voltage
14 bits / 0.2%
2% accuracy for Ext Ref Level, Unit gain
adjustable between 0 and EO
NOM
/10 (voltage)
or IO
NOM
/10 (current).
Current
14 bits / 0.5%
Voltage Limit
12 bits / 0.5%
Current Limit
12 bits / 0.5%
Readback
resolution / accuracy
Voltage
16 bits / 0.2%
main or limit channel
Current
16 bits / 0.5%
main or limit channel
TABLE 2. EQUIPMENT SUPPLIED (CONTINUED)
Item
Quantity
Purpose
Kepco Part
Number
