KEPCO KIT 219-0481, Kit for connecting three series-connected 1000W BOPs in two parallel branches (3X2) User Manual
Cable, Kepco

©2012, KEPCO, INC
Data subject to change without notice
228-1523 REV 3
033012
I N S T R U C T I O N S H E E T
KEPCO
KEPCO, INC. 131-38 SANFORD AVENUE FLUSHING, NY. 11355 U.S.A. TEL (718) 461-7000 FAX (718) 767-1102
http://www.kepcopower.com email: [email protected]
An ISO 9001 Company.
CABLE
219-0481
KIT
CABLE KIT NO. 219-0481
BOP 1000W MODELS 3 X 2 COMBINATION
I.
DESCRIPTION.
This kit contains the cables and terminations required to operate a multiple unit combination consisting of two
parallel branches each comprised of three identical 1000 Watt BOP High Power models in series, effectively tri-
pling the output voltage and doubling the output current capacity. Only identical models may be configured to
operate in parallel and series.
This kit can be used with all 1000W BOP models that have revision levels as shown in Table 1. Earlier models
that have been upgraded to permit multiple unit configurations must include the letter “A” following the revision
number. CAUTION: Failure to install the ground cables supplied can result in damage to the power supply.
Refer to the associated technical manual supplied with the 1000W BOP power supply for all instructions regard-
ing installation and operation of multiple units in parallel.
II.
SPECIFICATIONS
Table 3 lists the model parameters unique to a 3 X 2 multiple unit combination of identical 1000W BOP Power
Supplies (three series-connected units X two parallel branches). Table 4 lists the general specifications applicable
to all 3 X 2 multiple unit combinations listed in Table 3. For specifications not listed in Table 3, refer to the General
Specifications provided in the associated technical manual supplied with each 1000W BOP power supply.
TABLE 1. REVISION LEVELS APPLICABLE TO THIS KIT
MG Model
Revision
Revisions for previously Upgraded
Units (Must include “A”)
GL Model
Revision
BOP 6-125MG
All
All
BOP 10-75MG
5 or higher
3A or 4A
BOP 20-50MG
8 or higher
5A, 6A or 7A
BOP 20-50GL
All
BOP 25-40MG
All
All
BOP 36-28MG
11 or higher
8A, 9A or 10A
BOP 50-20MG
7 or higher
5A or 6A
BOP 50-20GL
All
BOP 72-14MG
7 or higher
6A
BOP 100-10MG
6 or higher
2A or 4A
TABLE 2. EQUIPMENT SUPPLIED
Item
Quantity
Purpose
Kepco Part
Number
Parallel power cable, **
(4.5 ft.)
2
Connects the OUTPUT terminal of Slave #2 to the OUTPUT terminal of Slave
#5 and the COMMON terminal of Master to the COMMON terminal of Slave #3.
118-1155
Series Power cable,
(1.5 ft.)
4
Connects the OUTPUT terminal of Master to the COMMON terminal of Slave
#1, OUTPUT terminal of Slave #1 to the COMMON terminal of Slave #2, OUT-
PUT terminal of Slave #3 to the COMMON terminal of Slave #4, and OUTPUT
terminal of Slave #4 to the COMMON terminal of Slave #5.
118-1112
Configuration Control cable,
(2.5 ft.)
1
Connects the PAR/SER CONTROL - IN ports of the Master and Slave #3
together to provide control signals needed to establish a series-parallel configu-
ration
118-1158
Series Control cable, (1.5 ft.)
4
Provides control signals required for series operation.
118-1120
** For GL units: Unclamp and remove ferrite from cable before installation.
!
