KEPCO KIT 219-0480, Kit for connecting two series-connected 1000W BOPs in two parallel branches (2X2) User Manual

Page 2

background image

KEPCO, INC. 131-38 SANFORD AVENUE FLUSHING, NY. 11355 U.S.A. TEL (718) 461-7000

FAX (718) 767-1102 email: [email protected]

2

228-1524 REV 3

033012

Protection Cable (1 ft.)

3

Provides interlock protection signals required for multiple unit operation.

118-1126

Protection - OUT

Termination (Slave)

1

Provides proper termination for the slave connection to the Protection
Cable.

195-0108

Protection - IN

Termination (Master)

1

Provides proper termination for the master connection to the Protection
Cable.

195-0107

Chassis Ground Cable

2

Connects chassis ground terminals of all units.

118-1272

Ground Cable mounting

hardware

4 sets

Each set consists of eight parts, mounted in the following order: No. 10 star
lockwasher P/N 103-0106 (at chassis), No. 10 flat washer P/N 103-0031,
No. 10 split lockwasher P/N 103-0033, 10-32X3/8 nut P/N 102-0008, No. 10
flat washer P/N 103-0031, [lug(s) from ground cable], No. 10 flat washer P/N
103-0031, No. 10 split lockwasher P/N 103-0033, and 10-32X3/8 nut P/N
102-0008.

(See

Purpose

at left for part

numbers)

Output Sense Cable

2

Connects Output sense terminal to Common sense terminal of next unit.

118-1271

Nut

2

Overcomes tight space for output cable connections. After securing bottom
cable to output terminal stud using one nut, additional cables can be ori-
ented for best layout and secured with separate nut.

102-0046

Instruction Manual

1

Lists material supplied and specifications for multiple unit combination.

228-1524

TABLE 3. MODEL PARAMETERS FOR 2 X 2 CONFIGURATION OF FOUR (4) IDENTICAL BOP 1000W UNITS

(2 SERIES-CONNECTED UNITS X 2 PARALLEL BRANCHES)

(4) Identical Models

(2 Series x 2 Parallel)

d-c Output Range

Closed Loop Gain

E

O Max

I

O Max

Voltage Channel

(V/V)

Current Channel

(A/V)

BOP 6-125MG

±12V d-c

±250A d-c

1.2

25.0

BOP 10-75MG

±20V d-c

±150A d-c

2.0

15.0

BOP 20-50MG

±40V d-c

±100A d-c

4.0

10.0

BOP 25-40MG

±50V d-c

±80A d-c

5.0

8.0

BOP 36-28MG

±72V d-c

±56A d-c

7.2

5.6

BOP 50-20MG

±100V d-c

±40A d-c

10.0

4.0

BOP 72-14MG

±144V d-c

±28A d-c

14.4

2.8

BOP 100-10MG

±200V d-c

±20A d-c

20.0

2.0

TABLE 4. GENERAL SPECIFICATIONS FOR BOP 1000W 2 X 2 CONFIGURATION

(2 IN SERIES, 2 PARALLEL BRANCHES)

SPECIFICATION

RATING/DESCRIPTION

CONDITION

INPUT CHARACTERISTICS

Current 176

Va-c

38A

a-c

maximum

264 Va-c

25.6A a-c

maximum

Leakage current

14.0mA a-c

230V a-c, 47-63 Hz

OUTPUT CHARACTERISTICS

Programming
resolution/accuracy

Voltage

14 bits / 0.2%

2% accuracy for Ext Ref Level. Unit gain
adjustable between 0 and E

ONOM

/10 (voltage)

or I

ONOM

/10 (current).

Current

14 bits / 0.5%

Voltage Limit

12 bits / 0.5%

Current Limit

12 bits / 0.5%

Readback
resolution/accuracy

Voltage

16 bits / 0.2%

main or limit channel

Current

16 bits / 0.5%

main or limit channel

TABLE 2. EQUIPMENT SUPPLIED (CONTINUED)

Item

Quantity

Purpose

Kepco Part Number
