KEPCO KIT 219-0480, Kit for connecting two series-connected 1000W BOPs in two parallel branches (2X2) - Manual

©2012, KEPCO, INC
Data subject to change without notice
228-1524 REV 3 033012
I N S T R U C T I O N S H E E T
KEPCO
KEPCO, INC. 131-38 SANFORD AVENUE FLUSHING, NY. 11355 U.S.A. TEL (718) 461-7000 FAX (718) 767-1102
http://www.kepcopower.com email: [email protected]
An ISO 9001 Company.
CABLE
219-0480
KIT
CABLE KIT NO. 219-0480
BOP 1000W MODELS 2 X 2 COMBINATION
I. DESCRIPTION.
This kit contains the cables and terminations required to operate a multiple unit combination consisting of two
parallel branches each comprised of two identical 1000 Watt BOP High Power models in series, effectively dou-
bling the output voltage and doubling the output current capacity. Only identical models may be configured to
operate in parallel and series.
This kit can be used with all 1000W BOP models that have revision levels as shown in Table 1. Earlier models
that have been upgraded to permit multiple unit configurations must include the letter “A” following the revision
number. CAUTION: Failure to install the ground cables supplied can result in damage to the power supply.
Refer to the associated technical manual supplied with the 1000W BOP power supply for all instructions regard-
ing installation and operation of multiple units in parallel.
II. SPECIFICATIONS
Table 3 lists the model parameters unique to a 2 X 2 multiple unit combination of identical 1000W BOP Power
Supplies (two series-connected units X two parallel branches). Table 4 lists the general specifications applicable
to all 2 X 2 multiple unit combinations listed in Table 3. For specifications not listed in Table 3, refer to the General
Specifications provided in the associated technical manual supplied with each 1000W BOP power supply.
TABLE 1. REVISION LEVELS APPLICABLE TO THIS KIT
MG Model Revision
Revisions for previously Upgraded
Units (Must include “A”)
GL Model Revision
BOP 6-125MG All All
BOP 10-75MG 5 or higher 3A or 4A
BOP 20-50MG 8 or higher 5A, 6A or 7A BOP 20-50GL All
BOP 25-40MG All All
BOP 36-28MG 11 or higher 8A, 9A or 10A
BOP 50-20MG 7 or higher 5A or 6A BOP 50-20GL All
BOP 72-14MG 7 or higher 6A
BOP 100-10MG 6 or higher 2A or 4A
TABLE 2. EQUIPMENT SUPPLIED
Item Quantity Purpose Kepco Part Number
Common power
cable, ** (4.5 ft.)
1
Connects the COMMON terminal of Master to the COMMON terminal of
Slave #3.
118-1155
Output/Series Power
cable, (1.5 ft.)
3
Connects the OUTPUT terminal of Master to the COMMON terminal of
Slave #1, OUTPUT terminal of Slave #1 to the OUTPUT terminal of Slave
#2, and COMMON terminal of Slave #2 to the OUTPUT terminal of Slave #3
118-1112
Configuration Control
cable, (2.5 ft)
1
Connects the PAR/SER CONTROL - IN ports of the Master and Slave #3
together to provide control signals needed to establish a series-parallel con-
figuration
118-1158
Series Control cable,
(1.5 ft.)
2
Provides control signals required for series operation.
118-1120
Digital Control (Bitbus)
Cable, (4.5 ft.)
1
Provides communication between master and three slaves comprised of two
series-connected units arranged in 2 parallel branches.
118-1149
** For GL units: Unclamp and remove ferrite from cable before installation.
!
