KEPCO, INC. 131-38 SANFORD AVENUE FLUSHING, NY. 11355 U.S.A. TEL (718) 461-7000
FAX (718) 767-1102 email: [email protected]
2
228-1528 REV 3 033012
Output Power cable,
(6 ft.)
1
Connects the OUTPUT terminal of Master to the OUTPUT terminal of Slave
#4.
118-1156
Digital Control (Bitbus) Cable,
(6 ft)
1
Provides communication between master and four slaves.
118-1150
Parallel Control Cable
(1.5 ft.)
4
Provides control signals required for parallel operation.
118-1119
Protection Cable
(1 ft.)
4
Provides interlock protection signals required for multiple unit operation.
118-1126
Master - IN Parallel Control
Termination
1
Provides proper termination for Parallel Control Cable.
195-0109
Protection - OUT Termina-
tion (Slave)
1
Provides proper termination for the slave connection to the Protection Cable.
195-0108
Protection - IN Termination
(Master)
1
Provides proper termination for the master connection to the Protection Cable.
195-0107
Chassis Ground Cable 4 Connects chassis ground terminals of all units. 118-1272
Ground Cable mounting
hardware
5 sets Each set consists of eight parts, mounted in the following order: No. 10 star
lockwasher P/N 103-0106 (at chassis), No. 10 flat washer P/N 103-0031, No.
10 split lockwasher P/N 103-0033, 10-32X3/8 nut P/N 102-0008, No. 10 flat
washer P/N 103-0031, [lug(s) from ground cable], No. 10 flat washer P/N 103-
0031, No. 10 split lockwasher P/N 103-0033, and 10-32X3/8 nut P/N 102-0008. (See
Purpose
at left for part
numbers)
Nut 2 Overcomes tight space for output cable connections. After securing bottom
cable to output terminal stud using one nut, additional cables can be oriented
for best layout and secured with separate nut. 102-0046
Instruction Manual 1 Lists material supplied and specifications for multiple unit combination. 228-1528
TABLE 3. MODEL PARAMETERS FOR FIVE (5) IDENTICAL BOP 1000 WATT UNITS (PARALLEL)
(5) Identical Models
(Parallel)
d-c Output Range Closed Loop Gain
E
O Max
I
O Max
Voltage Channel
(V/V)
Current Channel
(A/V)
BOP 6-125MG ±6V d-c ±625A d-c 0.6 62.5
BOP 10-75MG ±10V d-c ±375A d-c 1.0 37.5
BOP 20-50MG ±20V d-c ±250A d-c 2.0 25.0
BOP 25-40MG ±25V d-c ±200A d-c 2.5 20.0
BOP 36-28MG ±36V d-c ±140A d-c 3.6 14.0
BOP 50-20MG ±50V d-c ±100A d-c 5.0 10.0
BOP 72-14MG ±72V d-c ±70A d-c 7.2 7.0
BOP 100-10MG ±100V d-c ±50A d-c 10.0 5.0
TABLE 4. GENERAL SPECIFICATIONS FOR FIVE (5) IDENTICAL BOP 1000 WATT UNITS (PARALLEL)
SPECIFICATION RATING/DESCRIPTION CONDITION
INPUT CHARACTERISTICS
Current 176 Va-c 47.5A a-c maximum
264 Va-c 32.0A a-c maximum
Leakage current 17.5mA a-c 230V a-c, 47-63 Hz
OUTPUT CHARACTERISTICS
Programming
resolution / accuracy Voltage 14 bits / 0.2% 2% accuracy for Ext Ref Level. Unit gain
adjustable between 0 and E
ONOM
/10 (voltage)
or I
ONOM
/10 (current).
Current 14 bits / 0.5%
Voltage Limit 12 bits / 0.5%
Current Limit 12 bits / 0.5%
Readback
resolution / accuracy Voltage 16 bits / 0.2% main or limit channel
Current 16 bits / 0.5% main or limit channel
TABLE 2. EQUIPMENT SUPPLIED (CONTINUED)
Item Quantity Purpose
Kepco Part
Number
