KEPCO, INC. 131-38 SANFORD AVENUE FLUSHING, NY. 11355 U.S.A. TEL (718) 461-7000
FAX (718) 767-1102 email: [email protected]
2
228-1486 REV 2 033012
Protection - OUT
Termination (Slave)
1
Provides proper termination for the slave connection to the
Protection Cable.
195-0108
Protection - IN
Termination (Master)
1
Provides proper termination for the master connection to the
Protection Cable.
195-0107
Chassis Ground Cable 1 Connects chassis ground terminals of all units. 118-1272
Ground Cable mounting
hardware
2 sets Each set consists of eight parts, mounted in the following order:
No. 10 star lockwasher P/N 103-0106 (at chassis), No. 10 flat
washer P/N 103-0031, No. 10 split lockwasher P/N 103-0033, 10-
32X3/8 nut P/N 102-0008, No. 10 flat washer P/N 103-0031,
[lug(s) from ground cable], No. 10 flat washer P/N 103-0031, No.
10 split lockwasher P/N 103-0033, and 10-32X3/8 nut P/N 102-
0008. (See
Purpose
at left for part
numbers)
Output Sense Cable 1
Connects Output sense terminal to Common sense terminal of
next unit.
118-1271
Instruction Manual 1
Lists material supplied and specifications for multiple unit
combination.
228-1486
TABLE 3. MODEL PARAMETERS FOR TWO (2) IDENTICAL BOP 1000 WATT UNITS (SERIES)
(2) Identical Models
(Series)
d-c Output Range Closed Loop Gain
E
O Max
I
O Max
Voltage Channel
(V/V)
Current Channel
(A/V)
BOP 6-125MG ±12V d-c ±125A d-c 1.2 12.5
BOP 10-75MG ±20V d-c ±75A d-c 2.0 7.5
BOP 20-50MG ±40V d-c ±50A d-c 4.0 5.0
BOP 25-40MG ±50V d-c ±40A d-c 5.0 4.0
BOP 36-28MG ±72V d-c ±28A d-c 7.2 2.8
BOP 50-20MG ±100V d-c ±20A d-c 10.0 2.0
BOP 72-14MG ±144V d-c ±14A d-c 14.4 1.4
BOP 100-10MG ±200V d-c ±10A d-c 20.0 1.0
TABLE 4. GENERAL SPECIFICATIONS FOR TWO (2) IDENTICAL BOP 1000 WATT UNITS (SERIES)
SPECIFICATION RATING/DESCRIPTION CONDITION
INPUT CHARACTERISTICS
Current 176
Va-c 19A a-c maximum
264 Va-c 12.8A a-c maximum
Leakage current 7mA a-c 230V a-c, 47-63 Hz
OUTPUT CHARACTERISTICS
Programming
resolution / accuracy
Voltage 14 bits / 0.2% 2% accuracy for Ext Ref Level. Unit gain
adjustable between 0 and E
ONOM
/10
(voltage) or I
ONOM
/10 (current).
Current 14 bits / 0.5%
Voltage Limit 12 bits / 0.5%
Current Limit 12 bits / 0.5%
Readback
resolution / accuracy Voltage 16 bits / 0.2% main or limit channel
Current 16 bits / 0.5% main or limit channel
TABLE 2. EQUIPMENT SUPPLIED (CONTINUED)
Item Quantity Purpose
Kepco Part
Number
