KEPCO Kit 219-0436, RS232 Cable Adapter Kit (RJ45 to DB9) - Manual

©2008, KEPCO, INC
Data subject to change without notice
228-1487 REV 4 051408
I N S T R U C T I O N S H E E T
KEPCO
KEPCO, INC. " 131-38 SANFORD AVENUE " FLUSHING, NY. 11355 U.S.A. " TEL (718) 461-7000 " FAX (718) 767-1102
http://www.kepcopower.com " email: [email protected]
An ISO 9001 Company.
CABLE
219-0436
KIT
RS 232 ADAPTER KIT
KIT NO. 219-0436
I. DESCRIPTION.
This kit is used to connect the RS232 port of a Kepco power supply to a computer using a 9-pin DB9 type connec-
tor. The kit contains one 1-meter long RJ45 (male) to RJ45 (male) patch cord for ABC and BHK-MG models, and
one 1-meter long RJ11 (male) to RJ45 (male) patch cord for BOP models, two loopback test connectors (one for
ABC and BHK-MG and one for BOP models) and two RJ45 to DB9 adapters (one with male pins and one with
female pins). Both adapters have a female RJ45 connector that accommodates one end of either patch cord.
Table 1 lists the items supplied in this kit.
II. ADAPTER ASSEMBLY
The RJ45 to DB9 adapters provided are not fully assembled because there are many different connection possi-
bilities. They must be must be assembled before they can be used. Figure 1 shows the connections for a typical
application using the adapter with female pins (P/N 142-0506) to connect to a standard IBM PC computer. Refer
to Table 2 for RJ45 pin functions to wire non-standard configurations.
1. Remove the metal connector from the plastic housing.
2. Snap in pins connected to the wires as defined in Table 2 into pins 5, 3 and 2 of the DB9 connector.
3. Fold the unused wires out of the way and snap the connector into the plastic housing
4. After the adapter is assembled, plug the RJ11-RJ45 patch cord into the BOP power supply RS 232 port,
or plug the RJ45 patch cord into the ABC or BHK-MG power supply RS 232 port.
5. Plug the RJ45 end of the patch cord into the assembled adapter, then plug the DB9 connector of the
adapter into the external controller and secure with the thumbscrews on the plastic housing.
TABLE 1. EQUIPMENT SUPPLIED
Item Quantity Purpose Kepco Part Number
RJ45 Patch Cord 1
Connects to Kepco BHK-MG or ABC power supply RS 232 port and
either DB9 adapter supplied.
118-1115
(L-COM TRD855-10)
RJ11-RJ45 Patch
Cord
1
Connects to Kepco BOP power supply RS 232 port and either DB9
adapter supplied.
118-1164
RJ45 to DB9 Adapter
(Female pins)
1
Connects to either Patch Cord (supplied) and external controller
using DB9 connector (female).
142-0506
(L-COM RA098F)
RJ45 to DB9 Adapter
(Male pins)
1
Connects to either Patch Cord (supplied) and external controller
using DB9 connector (male).
142-0487
(L-COM RA098M)
Loop Back Test
Connector
2
Allows testing of RS 232 communication and aids in troubleshooting
RS 232 communication problems.
195-0110 (fABC, BHK-MG only)
195-0111 (BOP only)
Instruction
Sheet
1 Provides assembly instructions 228-1487
