O P E R A T O R M A N U A L
KEPCO
An ISO 9001 Company.
JBW
100W SERIES
100 WATT SINGLE OUTPUT
SWITCHING POWER SUPPLIES
I — INTRODUCTION
SCOPE OF MANUAL. This instruction manual covers
the installation and operation of the Kepco JBW 100W
Series of RoHS (Reduction of Hazardous Substances)
compliant Switching Power Supplies.
DESCRIPTION. The Kepco JBW 100W Series consists
of four models of switching power supplies, each with a sin-
gle output as shown in Table 1. Units may be operated with
a nominal 100 to 120V a-c and 220 to 240V a-c (input volt-
age range 85 to 265 Va-c), 50-60 Hz (input frequency
range 47-440Hz.) They will also operate on 120V to 370V
d-c input. The JBW 100W Series employs a light weight fer-
rite core. Regulation is provided by pulse width modulation.
Power Factor Correction (PFC) is provided by a boost con-
verter operating at 80kHz. A FET power stage, operating
as a forward converter with a fixed switching frequency of
150kHz provides a smooth isolated d-c output. A thermistor
circuit prevents excessive turn-on current surge. Overvolt-
age protection is provided. Current limiting with automatic
recovery from short circuit is featured. Units are manufac-
tured on an open frame PC board.
Table 1 contains specifications and operating limits of indi-
vidual JBW 100 Series models. Section II (following) con-
tains specifications and operating limits common to all JBW
75W Series Models
II — SPECIFICATIONS
The following specifications are at nominal input voltages
and 25°C and apply to all models unless otherwise speci-
fied.
INPUT CHARACTERISTICS:
INPUT VOLTAGE: (0 to 100% load, -10 to 60°C)
Nominal 100-120V a-c, 220-240V a-c
Range: 85-265V a-c, 120 -370V d-c
NOTE: The power supply may shut down if operated at
below the input voltage range or if the input voltage
increases slowly at start up (> 1 second). To reset the
power supply, unplug the unit, wait one minute and
reapply input power.
INPUT SOURCE FREQUENCY:
Nominal 50/60 Hz;
Range 47-66 Hz (Above 66Hz to 440 Hz the leakage
current may exceed the VDE safety specification limit.)
INPUT CURRENT: (100% load at 25°C with nominal out-
put voltage):
100V a-c input: 1.3A typ., 1.8A max.
240V a-c input: 0.6A typ., 1.0A max.
INPUT PROTECTION AND SOFT START: A thermis-
tor circuit reduces start-up surge. Units are protected
against shorts by an input fuse. Fuse value 5A, 250V.
INPUT SURGE: Cold start:
100V a-c input, 100% load: 15A typ., 30.0A max.
240V a-c input, 100% load: 30A typ., 60.0A max.
TABLE 1. OUTPUT RATINGS AND SPECIFICATIONS, JBW 100W SERIES
MODEL JBW 5-20K JBW 12-8.5K JBW 15-6.7K JBW 24-4.3K
OUTPUT VOLTS, d-c 5V ±0.25V 12V ±0.6V 15V ±0.75V 24V ±1.2V
ADJUSTMENT RANGE 4.5-5.5V 10.8-13.2V 13.5-16.5V 21.6-26.4V
CURRENT/MAX. POWER RATINGS 20.0A/100W 8.5A/102W 6.7A/100.5W 4.3A(1)/103.2W
OVERCURRENT (AMPS) 21.0 min. 10.6 min. 8.38 min. 5.38 min
OVP RANGE (VOLTS) 5.75-6.9 13.8-16.8 17.2-21.0 27.6-33.6
EFFICIENCY (typ.)
100 Va-c 78% 80% 80% 82%
240 Va-c 80% 82% 82% 85%
ACCEPTABLE EXTERNAL OUTPUT CAPACITOR
µFmax., (fixed load resistance)
30,000 30,000 30,000 30,000
RIPPLE AND
NOISE
(2)
(mV p-p)
ripple (typ) 80 120 120 120
ripple (typ) (-10 to 0 °C) 140 160 160 160
spike noise (typ) 120 150 150 150
spike noise (typ)
(-10 to 0 °C)
160 180 180 180
(1) 5.0A peak, t
≤
10 seconds, not to exceed 4.3A rms, output power
≤
100W.
(2) 0 to 100% load, 0 to 60 °C, tested with 100µF electrolytic and 0.1µF film capacitors across the measuring points, connected to the
power supply via 5.9 in (150mm) wires; oscilloscope bandwidth
≤
20MHz.
