KEPCO DIN KIT PTR (L) User Manual

Kepco, Din ptr-l din-rail mounting kit for series ptr

Data subject to change without notice

228-1304

I N S T R U C T I O N M A N U A L

KIT

KEPCO

KEPCO, INC. " 131-38 SANFORD AVENUE " FLUSHING, NY. 11352 U.S.A. " TEL (718) 461-7000 " FAX (718) 767-1102

http://www.kepcopower.com " email: [email protected]

An ISO 9001 Company.

DIN PTR-L

DIN-RAIL MOUNTING KIT

FOR SERIES PTR

DESCRIPTION. Kepco KIT, Model DIN PTR-L contains two double mounting clip assemblies, and associated hard-

ware (see Table 1) used to install PTR Series power supplies on a DIN rail. The “L” suffix is for mounting along the long

dimension (length) as shown in Figure 1.

FIGURE 1. L SUFFIX ORIENTATION

TABLE 1. COMPONENTS SUPPLIED

KIT

MODEL NO.

CLIP

(QTY 4)

PART NO.

BRACKET (QTY 2)

PART NO.

SCREW (QTY 4)

PART NO.

WASHER (QTY 4)

PART NO.

DIN PTR-L

108-0362

128-1944

101-0279

(8-32 x 5/16”)

103-0032

(NO.8, SPLIT, LOCK)

NOTE: Clips and Brackets are supplied preassembled into double mounting clip assemblies. To replace a mounting
clip assembly, order both the clip and bracket and assemble per Figure 2 detail.
