LIST:VOLT, ?
SOURce:]LIST:VOLTage Command adds voltage
value (in Volts) to list. Query identifies parameters
(main channel) entered for list.
LIST:VOLT
:POIN?
SOURce:]LIST:VOLTage:POINts? Query identifies
total number of points in a list.
CURR, ?
SOURce:]CURRent[:LEVel][:IMMediate][:AMPli-
tude] Command programs output current (actual
current depends on load). Query shows pro-
grammed current or maximum/minimum current
allowed.
CURR:MODE, ?
SOURce:]CURRent:MODe Command allows user
to execute (LIST) or stop (FIX) a list, or to execute
a transient (TRAN). Query identifies active current
mode.
CURR:RANG, ?
[SOURce:]CURRent:[:LEVel]RANGe Command
sets output current range, 1 = full scale, 4 = 1/4
scale. Query shows programmed current range.
CURR:RANG
:AUTO
[SOURce:]CURRent:[:LEVel]RANGe:AUTO Com-
mand sets current range to automatic.
CURR:TRIG, ?
SOURce:]CURRent[:LEVel]TRIGgered[:AMPli-
tude] Command programs current value of trigger.
Query shows programmed value.
VOLT, ?
[SOURce:]VOLTage[:LEVel][:IMMediate][:AMPli-
tude] Command programs output voltage (actual
voltage depends on load). Query returns pro-
grammed value.
VOLT:MODE
SOURce:]VOLTage:MODE Command allows user
to execute (LIST) or stop (FIX) a list, or to execute
a transient (TRAN). Query identifies active voltage
mode.
VOLT:RANG, ?
[SOURce:]VOLTage[:LEVel]:RANGe Command
sets output voltage range, 1 = full scale, 4 = 1/4
scale. Query shows programmed voltage range.
VOLT:RANG
:AUTO
[SOURce:]VOLTage:[:LEVel]RANGe:AUTO Com-
mand sets voltage range to automatic.
VOLT:TRIG, ?
SOURce:]VOLTage[:LEVel]TRIGgered[:AMPli-
tude] Command programs voltage value of trigger.
Query shows programmed value.
STAT:OPER
:COND?
STATus:OPERation:CONDition Query returns
value of the Operation Condition Register.
STAT:OPER
:ENAB
STATus:OPERation:ENABle Command sets Oper-
ation Enable Register mask. Query reads register.
STAT:OPER?
STATus:OPERation[:EVENt] Query returns the
value of the Operation Event register.
STAT:PRES
STATus:PRESet Command disables reporting of
all status events.
STAT:QUES?
STATus:QUEStionable[:EVENt]? Query returns
value of Questionable Event register.
STAT:QUES
:COND?
STATus:QUEStionable:CONDition? Query returns
value of Questionable Condition Register.
TABLE 4. SCPI COMMANDS/QUERIES (CONT)
COMMAND
Function
STAT:QUES
:ENAB, ?
STATus:QUEStionable:ENABle Command pro-
grams Questionable Condition Enable register.
Query reads register.
SYST:BEEP
SYSTem:BEEP Command causes the unit to emit
a brief audible tone.
SYST:COMM
:SER:ECHO, ?
SYSTem:COMMunication:SERial:ECHO Com-
mand enables (ON) or disables (OFF) echo mode.
Query indicates if echo is on or off.
SYST:COMM
:SER:PACE, ?
SYSTem:COMMunication:SERial:PACE Com-
mand enables (XON) or disables (NONE) data flow
control via the serial interface. Query shows
enabled or disabled.
SYST:ERR?
SYSTem:ERRor? Query posts error messages to
the output queue.
SYST:ERR
:CODE?
SYSTem:ERRor:CODE? Query returns 3-charac-
ter error code without the ASCII definition string.
SYST:ERR
:CODE:ALL?
SYSTem:ERRor:CODE:ALL? Query returns a
comma-separated list of all error codes.
SYST:PASS
:CEN
SYSTem:PASSword:CENable Command Sets
password enable if password matches.
SYST:PASS
:CDIS
SYSTem:PASSword:CDISable Command disables
password access if password matches.
SYST:PASS
:NEW
SYSTem:PASSword:NEW Command establishes
new password.
SYST:PASS
:STAT?
SYSTem:PASSword:STATe? Query shows pass-
word state: enabled (1) or disabled (0).
SYST:REM,
SYSTem:REMote Command sets unit to remote (1
or ON) or local (0 or OFF) mode if using RS 232.
Query shows programmed mode.
SYST:SEC:IMM
SYSTem:SECurity:IMMediate Command initial-
izes all NVRAM variables to factory defaults.
SYST:SET, ?
SYSTem:SET Command establishes Device
Clear, Line Feed, and Reset functions. Query
shows programmed functions.
SYST:VERS?
SYSTem:VERSion? Query identifies SCPI Version
implemented.
TABLE 4. SCPI COMMANDS/QUERIES (CONT)
COMMAND
Function
